TDK-Lambda CCG15 DC/DC Converter, 3.3V dc/ 4 A, 76V dc Input, 18V Input 13.2 W, Through Hole, 85 °C Max Temp -40 °C Min
- RS Stock No.:
- 126-3520
- Mfr. Part No.:
- CCG15-48-03S
- Brand:
- TDK-Lambda
Bulk discount available
Subtotal (1 unit)*
£27.44
(exc. VAT)
£32.93
(inc. VAT)
Stock information currently inaccessible - Please check back later
Units | Per unit |
|---|---|
| 1 - 4 | £27.44 |
| 5 - 9 | £26.62 |
| 10 - 24 | £25.80 |
| 25 - 49 | £24.98 |
| 50 + | £24.16 |
*price indicative
- RS Stock No.:
- 126-3520
- Mfr. Part No.:
- CCG15-48-03S
- Brand:
- TDK-Lambda
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | TDK-Lambda | |
| Product Type | DC/DC Converter | |
| Output Voltage 1 | 3.3V dc | |
| Minimum Input Voltage | 18V | |
| Maximum Input Voltage | 76V dc | |
| Output Current 1 | 4A | |
| Output Current 2 | 4A | |
| Mount Type | Through Hole | |
| Number of Outputs | 1 | |
| MTBF | 3191064h | |
| Output Voltage Adjustment Range | 5.5 V | |
| Ripple and Noise | 95mV Pk-Pk | |
| Number of Pins | 6 | |
| Isolation Voltage | 500V dc | |
| Package Type | DIP | |
| Maximum Output Power | 13.2W | |
| Length | 25.4mm | |
| Depth | 9.9mm | |
| Width | 9.9mm | |
| Standards/Approvals | CE, EN 60950-1, UL/CSA 60950-1 | |
| Weight | 20g | |
| Series | CCG15 | |
| Maximum Operating Temperature | 85°C | |
| Efficiency | 85% | |
| Minimum Operating Temperature | -40°C | |
| Select all | ||
|---|---|---|
Brand TDK-Lambda | ||
Product Type DC/DC Converter | ||
Output Voltage 1 3.3V dc | ||
Minimum Input Voltage 18V | ||
Maximum Input Voltage 76V dc | ||
Output Current 1 4A | ||
Output Current 2 4A | ||
Mount Type Through Hole | ||
Number of Outputs 1 | ||
MTBF 3191064h | ||
Output Voltage Adjustment Range 5.5 V | ||
Ripple and Noise 95mV Pk-Pk | ||
Number of Pins 6 | ||
Isolation Voltage 500V dc | ||
Package Type DIP | ||
Maximum Output Power 13.2W | ||
Length 25.4mm | ||
Depth 9.9mm | ||
Width 9.9mm | ||
Standards/Approvals CE, EN 60950-1, UL/CSA 60950-1 | ||
Weight 20g | ||
Series CCG15 | ||
Maximum Operating Temperature 85°C | ||
Efficiency 85% | ||
Minimum Operating Temperature -40°C | ||
TDK-Lambda CCG15 Series Isolated DC-DC Converters
The CCG15 Series DC-DC Converters are enclosed in a metal case with 6-sided shielding for lower noise and encapsulated for strong shock and vibration performance. These high efficiency converters will operate in ambient temperatures of -40°C to +85°C. Typical applications for this series are test and measurement, broadcast, communication, general purpose industrial,factory automation and process control.
Features and Benefits
• Wide Range DC Input 9-36 or 18-76V
• Industry Standard 1" x 1" Footprint
• High Efficiency - Up to 88%
• Remote on/off
• Adjustable Output
• Six Sided Shielding
• Easier System Thermal Management
• Reduced Radiated Noise
TDK-Lambda Isolated DC-DC Converters, CCG Series
