XP Power DDC30 DC/DC Converter, 9 V dc/ 4 A, 12V dc Input, 12V dc Input, DIN Rail 36 W, 70 °C Max Temp -40 °C Min Temp,
- RS Stock No.:
- 516-916
- Mfr. Part No.:
- DDC4024S09
- Brand:
- XP Power
Subtotal (1 unit)*
£57.53
(exc. VAT)
£69.04
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 10 August 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £57.53 |
*price indicative
- RS Stock No.:
- 516-916
- Mfr. Part No.:
- DDC4024S09
- Brand:
- XP Power
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | XP Power | |
| Product Type | DC/DC Converter | |
| Output Voltage 1 | 9 V dc | |
| Minimum Input Voltage | 12V dc | |
| Maximum Input Voltage | 12V dc | |
| Output Current 1 | 4A | |
| Mount Type | DIN Rail | |
| Number of Outputs | 1 | |
| MTBF | 560kH | |
| Ripple and Noise | 100mV Pk-Pk | |
| Isolation Voltage | 1500V | |
| Number of Pins | 7 | |
| Maximum Output Power | 36W | |
| Width | 91 mm | |
| Depth | 56mm | |
| Length | 53mm | |
| Weight | 0.396lb | |
| Series | DDC30 | |
| Standards/Approvals | CSA C22.2 62368-1, EN61000-4-4, EN61000-4-5, EN61000-4-3, EN61000-4-8, TUV EN62368-1, EN61000-4-2, UL508, EN61000-4-6, UL62368-1, CB IEC62368-1, EN55032 | |
| Efficiency | 81.85% | |
| Minimum Operating Temperature | -40°C | |
| Maximum Operating Temperature | 70°C | |
| Select all | ||
|---|---|---|
Brand XP Power | ||
Product Type DC/DC Converter | ||
Output Voltage 1 9 V dc | ||
Minimum Input Voltage 12V dc | ||
Maximum Input Voltage 12V dc | ||
Output Current 1 4A | ||
Mount Type DIN Rail | ||
Number of Outputs 1 | ||
MTBF 560kH | ||
Ripple and Noise 100mV Pk-Pk | ||
Isolation Voltage 1500V | ||
Number of Pins 7 | ||
Maximum Output Power 36W | ||
Width 91 mm | ||
Depth 56mm | ||
Length 53mm | ||
Weight 0.396lb | ||
Series DDC30 | ||
Standards/Approvals CSA C22.2 62368-1, EN61000-4-4, EN61000-4-5, EN61000-4-3, EN61000-4-8, TUV EN62368-1, EN61000-4-2, UL508, EN61000-4-6, UL62368-1, CB IEC62368-1, EN55032 | ||
Efficiency 81.85% | ||
Minimum Operating Temperature -40°C | ||
Maximum Operating Temperature 70°C | ||
- COO (Country of Origin):
- TW
The XP Power DIN Rail mounting DC/DC converters designed to offer additional voltages in DIN Rail power systems, provide isolated outputs & noise immunity or support battery powered or battery backed applications
Class B conducted and radiated emissions
Low profile design
