TRACOPOWER, 2-Channel DC/DC Converter, 0/12 V dc, Dual D Type, 12V dc, -12 V dc, 1.25 A 6-Pin, 1 x 1 in
- RS Stock No.:
- 284-8839
- Distrelec Article No.:
- 303-69-442
- Mfr. Part No.:
- THL 30-2422WI
- Brand:
- TRACOPOWER
Subtotal (1 unit)*
£45.31
(exc. VAT)
£54.37
(inc. VAT)
FREE delivery for orders over £60.00
Temporarily out of stock
- 10 unit(s) shipping from 12 May 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £45.31 |
*price indicative
- RS Stock No.:
- 284-8839
- Distrelec Article No.:
- 303-69-442
- Mfr. Part No.:
- THL 30-2422WI
- Brand:
- TRACOPOWER
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | TRACOPOWER | |
| Product Type | DC/DC Converter | |
| Maximum Output Voltage | 12V dc | |
| Minimum Input Voltage | 9V | |
| Maximum Input Voltage | 36V dc | |
| Minimum Output Current | 1.25A | |
| Maximum Output Current | 1250mA | |
| Topology | DC-DC | |
| Output Type | 0/12 V dc, Dual D Type | |
| Mount Type | Through Hole | |
| Maximum Switching Frequency | 314kHz | |
| Minimum Operating Temperature | -40°C | |
| Package Type | 1 x 1 in | |
| Pin Count | 6 | |
| Maximum Operating Temperature | 60°C | |
| Standards/Approvals | EN 62368-1, IEC 62368-1, UL 62368-1 | |
| Height | 10.2mm | |
| Length | 25.4mm | |
| Series | THL | |
| Minimum Output Voltage | -12V dc | |
| Automotive Standard | No | |
| Select all | ||
|---|---|---|
Brand TRACOPOWER | ||
Product Type DC/DC Converter | ||
Maximum Output Voltage 12V dc | ||
Minimum Input Voltage 9V | ||
Maximum Input Voltage 36V dc | ||
Minimum Output Current 1.25A | ||
Maximum Output Current 1250mA | ||
Topology DC-DC | ||
Output Type 0/12 V dc, Dual D Type | ||
Mount Type Through Hole | ||
Maximum Switching Frequency 314kHz | ||
Minimum Operating Temperature -40°C | ||
Package Type 1 x 1 in | ||
Pin Count 6 | ||
Maximum Operating Temperature 60°C | ||
Standards/Approvals EN 62368-1, IEC 62368-1, UL 62368-1 | ||
Height 10.2mm | ||
Length 25.4mm | ||
Series THL | ||
Minimum Output Voltage -12V dc | ||
Automotive Standard No | ||
The TRACOPOWER series of isolated 15 Watt converters which come in an ultra compact DIP-16 metal package. The design purpose of this series was to miniaturized low power DC/DC converters to the maximum without sacrificing high efficiency. It solidifies the new standard for power density with 4.51 W/cm3 and effectively doubles the power density compared to 15 Watt converters in DIP-24 packages. It offers a wide 4:1 input voltage range and features a high efficiency of up to 87% which enables an operation temperature of up to +55°C at full load and up to 85°C with 50% load. The converters also have an internal input filter to comply with conducted emission standard EN 55032 class A. It's an economical solution for space critical and cost sensitive applications in instrumentation, IT and industrial electronics
Ultra compact 15 Watt converter in DIP 16 metal casing
Highest power density
High efficiency
Protection against short circuit
