HARTING 956 62 Way Straight 2.41 mm Pitch Through Hole D-Sub Connector Female
- RS Stock No.:
- 666-1140
- Mfr. Part No.:
- 09564517500
- Brand:
- HARTING
Bulk discount available
Subtotal (1 unit)*
£10.54
(exc. VAT)
£12.65
(inc. VAT)
FREE delivery for orders over £60.00
In Stock
- Plus 7 unit(s) shipping from 27 April 2026
- Plus 50 unit(s) shipping from 01 July 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 - 49 | £10.54 |
| 50 - 99 | £9.47 |
| 100 - 249 | £8.46 |
| 250 - 499 | £7.38 |
| 500 + | £6.86 |
*price indicative
- RS Stock No.:
- 666-1140
- Mfr. Part No.:
- 09564517500
- Brand:
- HARTING
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | HARTING | |
| Product Type | D-Sub Connector | |
| Number of Contacts | 62 | |
| Orientation | Straight | |
| Current | 2A | |
| Mount Type | Through Hole | |
| Connector Gender | Female | |
| Connector Type D | D-Sub | |
| D-Sub Shell Size | DS-4 | |
| Housing Material | Metal | |
| Voltage | 1000V | |
| Minimum Operating Temperature | -40°C | |
| Termination Type | Solder | |
| Contact Gender | Female | |
| Maximum Operating Temperature | 85°C | |
| Standards/Approvals | No | |
| Series | 956 | |
| Contact Material | Copper Alloy | |
| Pitch | 2.41mm | |
| Select all | ||
|---|---|---|
Brand HARTING | ||
Product Type D-Sub Connector | ||
Number of Contacts 62 | ||
Orientation Straight | ||
Current 2A | ||
Mount Type Through Hole | ||
Connector Gender Female | ||
Connector Type D D-Sub | ||
D-Sub Shell Size DS-4 | ||
Housing Material Metal | ||
Voltage 1000V | ||
Minimum Operating Temperature -40°C | ||
Termination Type Solder | ||
Contact Gender Female | ||
Maximum Operating Temperature 85°C | ||
Standards/Approvals No | ||
Series 956 | ||
Contact Material Copper Alloy | ||
Pitch 2.41mm | ||
PCB Sockets
Harting D Sub High Density
The high density range exceeds the contact capacity of a standard subminiature D connector by 70%.
Stamped pins
Tinned metal shell (Male connector with dimples)
