Norcomp 190 9 Way Right Angle SMT D-sub Connector Socket, 2.77mm Pitch, with Boardlocks
- RS Stock No.:
- 174-8536
- Mfr. Part No.:
- 190-009-263R001
- Brand:
- Norcomp
Bulk discount available
Subtotal (1 tray of 15 units)*
£34.65
(exc. VAT)
£41.55
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- 180 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Tray* |
|---|---|---|
| 15 - 15 | £2.31 | £34.65 |
| 30 - 60 | £2.195 | £32.93 |
| 75 + | £2.087 | £31.31 |
*price indicative
- RS Stock No.:
- 174-8536
- Mfr. Part No.:
- 190-009-263R001
- Brand:
- Norcomp
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Norcomp | |
| Number of Contacts | 9 | |
| Gender | Female | |
| Body Orientation | Right Angle | |
| Mounting Type | Surface Mount | |
| Pitch | 2.77mm | |
| D Connector Type | Standard D-Sub | |
| Termination Method | Solder | |
| Mounting Hardware | Boardlocks | |
| Current Rating | 5.0A | |
| Housing Material | Steel | |
| Voltage Rating | 300.0 V, 500.0 V | |
| Length | 30.81mm | |
| Width | 10.1mm | |
| Depth | 12.55mm | |
| Series | 190 | |
| Dimensions | 30.81 x 10.1 x 12.55mm | |
| Contact Material | Phosphor Bronze | |
| Maximum Operating Temperature | +105°C | |
| Series Number | 190 | |
| Minimum Operating Temperature | -55.0°C | |
Select all | ||
|---|---|---|
Brand Norcomp | ||
Number of Contacts 9 | ||
Gender Female | ||
Body Orientation Right Angle | ||
Mounting Type Surface Mount | ||
Pitch 2.77mm | ||
D Connector Type Standard D-Sub | ||
Termination Method Solder | ||
Mounting Hardware Boardlocks | ||
Current Rating 5.0A | ||
Housing Material Steel | ||
Voltage Rating 300.0 V, 500.0 V | ||
Length 30.81mm | ||
Width 10.1mm | ||
Depth 12.55mm | ||
Series 190 | ||
Dimensions 30.81 x 10.1 x 12.55mm | ||
Contact Material Phosphor Bronze | ||
Maximum Operating Temperature +105°C | ||
Series Number 190 | ||
Minimum Operating Temperature -55.0°C | ||
- COO (Country of Origin):
- TW
Available in 9 and 25 position standard D-Sub.
Available in 15 position female High Density.
Metal shell provides shielding..
Plug shells have indents to provide grounding and additional retention.
Built in Board Locks add mechanical stability to pcb.
Shell: Steel-nickel plated
Insulator: Nylon black (260°C process temp)
Contacts: Male pins: Phosphor bronze | Female pins: Phosphor bronze
Plating: Gold flash (mating area) | Tin (solder tails)
Board Locks: Brass-Nickel plated
Available in 15 position female High Density.
Metal shell provides shielding..
Plug shells have indents to provide grounding and additional retention.
Built in Board Locks add mechanical stability to pcb.
Shell: Steel-nickel plated
Insulator: Nylon black (260°C process temp)
Contacts: Male pins: Phosphor bronze | Female pins: Phosphor bronze
Plating: Gold flash (mating area) | Tin (solder tails)
Board Locks: Brass-Nickel plated
