Norcomp 182 9 Way Right Angle Through Hole D-sub Connector Socket, 2.77mm Pitch, with 4-40 Flush Insert/Board Lock
- RS Stock No.:
- 174-8532
- Mfr. Part No.:
- 182-009-213R531
- Brand:
- Norcomp
Subtotal (1 tray of 90 units)*
£109.35
(exc. VAT)
£131.22
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- Plus 90 unit(s) shipping from 08 September 2025
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Tray* |
|---|---|---|
| 90 + | £1.215 | £109.35 |
*price indicative
- RS Stock No.:
- 174-8532
- Mfr. Part No.:
- 182-009-213R531
- Brand:
- Norcomp
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Norcomp | |
| Number of Contacts | 9 | |
| Gender | Female | |
| Body Orientation | Right Angle | |
| Mounting Type | Through Hole | |
| Pitch | 2.77mm | |
| D Connector Type | Standard D-Sub | |
| Termination Method | Solder | |
| Mounting Hardware | 4-40 Flush Insert/Board Lock | |
| Current Rating | 5.0A | |
| Voltage Rating | 1.0 kV | |
| Length | 30.81mm | |
| Width | 18.51mm | |
| Depth | 12.55mm | |
| Dimensions | 30.81 x 18.51 x 12.55mm | |
| Series | 182 | |
| Contact Plating | Gold Flash | |
| Contact Material | Brass | |
| Minimum Operating Temperature | -55.0°C | |
| Maximum Operating Temperature | +105°C | |
| Series Number | 182 | |
Select all | ||
|---|---|---|
Brand Norcomp | ||
Number of Contacts 9 | ||
Gender Female | ||
Body Orientation Right Angle | ||
Mounting Type Through Hole | ||
Pitch 2.77mm | ||
D Connector Type Standard D-Sub | ||
Termination Method Solder | ||
Mounting Hardware 4-40 Flush Insert/Board Lock | ||
Current Rating 5.0A | ||
Voltage Rating 1.0 kV | ||
Length 30.81mm | ||
Width 18.51mm | ||
Depth 12.55mm | ||
Dimensions 30.81 x 18.51 x 12.55mm | ||
Series 182 | ||
Contact Plating Gold Flash | ||
Contact Material Brass | ||
Minimum Operating Temperature -55.0°C | ||
Maximum Operating Temperature +105°C | ||
Series Number 182 | ||
