Harting D-Sub 15 Way Right Angle Through Hole D-sub Connector Socket, 2.77mm Pitch, with 4-40 UNC Screwlocks
- RS Stock No.:
- 139-3694
- Mfr. Part No.:
- 09682535613
- Brand:
- HARTING
100 In stock - FREE next working day delivery available
Added
Price Each (In a Pack of 50)
£4.494
(exc. VAT)
£5.393
(inc. VAT)
| Units | Per unit | Per Pack* |
| 50 - 50 | £4.494 | £224.70 |
| 100 - 200 | £3.82 | £191.00 |
| 250 - 450 | £3.371 | £168.55 |
| 500 + | £3.166 | £158.30 |
| *price indicative | ||
- RS Stock No.:
- 139-3694
- Mfr. Part No.:
- 09682535613
- Brand:
- HARTING
Technical Reference
Legislation and Compliance
- COO (Country of Origin):
- CN
Product Details
Harting 9, 15 and 25 way Solder D-Sub Miniature Sockets - U.S Footprint
From Harting, a range of solder D-Sub miniature connectors with stamped and angled female contacts. The U.S footprint sockets have copper alloy contacts in a robust metal shell with extra grounding pin. Secured in the panel with a fixing flange and 4 - 40 UNC screw lock. The D-Sub miniature connectors in this range have a performance level S2.
Features and Benefits
• Robust metal shell
• 6.5A rated current
• Wave solder termination
• Extra grounding pin
• U.S footprint
• Stamped angled contacts
• 6.5A rated current
• Wave solder termination
• Extra grounding pin
• U.S footprint
• Stamped angled contacts
D-Sub Connectors - Harting
Specifications
Attribute | Value |
|---|---|
| Number of Contacts | 15 |
| Gender | Female |
| Body Orientation | Right Angle |
| Mounting Type | Through Hole |
| Pitch | 2.77 mm, 2.84mm |
| D Connector Type | Standard D-Sub |
| Termination Method | Solder |
| Mounting Hardware | 4-40 UNC Screwlocks |
| Current Rating | 6.5A |
| Mixed Contact Layout | 15W2 |
| Housing Material | Glass Fibre Reinforced Thermoplastic |
| Length | 39.2mm |
| Width | 12.55mm |
| Depth | 18.2mm |
| Contact Material | Copper Alloy |
| Dimensions | 39.2 x 12.55 x 18.2mm |
| Series | D-Sub |
| Minimum Operating Temperature | -55.0°C |
| Maximum Operating Temperature | +125°C |
