Amphenol Communications Solutions DM 9 Way Cable Mount D-sub Connector Socket, 2.74mm Pitch
- RS Stock No.:
- 137-2505
- Mfr. Part No.:
- DEM09S
- Brand:
- Amphenol Communications Solutions
Subtotal (1 tray of 30 units)*
£200.04
(exc. VAT)
£240.06
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- 180 unit(s) shipping from 25 December 2025
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Tray* |
|---|---|---|
| 30 + | £6.668 | £200.04 |
*price indicative
Alternative
This product is not currently available. Here is our alternative recommendation.
Each
£7.51
(exc. VAT)
£9.01
(inc. VAT)
- RS Stock No.:
- 137-2505
- Mfr. Part No.:
- DEM09S
- Brand:
- Amphenol Communications Solutions
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Amphenol Communications Solutions | |
| Number of Contacts | 9 | |
| Gender | Female | |
| Body Orientation | Straight | |
| Mounting Type | Cable Mount | |
| Pitch | 2.74mm | |
| D Connector Type | Standard D-Sub | |
| D-Sub Shell Size | E | |
| Termination Method | Solder | |
| Current Rating | 7.5A | |
| Mixed Contact Layout | 9W2 | |
| Housing Material | Thermoplastic | |
| Voltage Rating | 1.0 kV | |
| Length | 30.43mm | |
| Width | 12.55mm | |
| Depth | 10.64mm | |
| Dimensions | 30.43 x 12.55 x 10.64mm | |
| Contact Material | Phosphor Bronze | |
| Contact Plating | Gold over Nickel | |
| Series | DM | |
| Minimum Operating Temperature | -55.0°C | |
| Maximum Operating Temperature | +125°C | |
Select all | ||
|---|---|---|
Brand Amphenol Communications Solutions | ||
Number of Contacts 9 | ||
Gender Female | ||
Body Orientation Straight | ||
Mounting Type Cable Mount | ||
Pitch 2.74mm | ||
D Connector Type Standard D-Sub | ||
D-Sub Shell Size E | ||
Termination Method Solder | ||
Current Rating 7.5A | ||
Mixed Contact Layout 9W2 | ||
Housing Material Thermoplastic | ||
Voltage Rating 1.0 kV | ||
Length 30.43mm | ||
Width 12.55mm | ||
Depth 10.64mm | ||
Dimensions 30.43 x 12.55 x 10.64mm | ||
Contact Material Phosphor Bronze | ||
Contact Plating Gold over Nickel | ||
Series DM | ||
Minimum Operating Temperature -55.0°C | ||
Maximum Operating Temperature +125°C | ||
