Abracon 20MHz Crystal Unit ±2.5ppm SMD 4-Pin 5 x 3.2 x 1.5mm
- RS Stock No.:
- 226-0777
- Mfr. Part No.:
- FT5HNBPK20.0-T1
- Brand:
- Abracon
Subtotal (1 reel of 1000 units)*
£1,330.00
(exc. VAT)
£1,600.00
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- 2,000 unit(s) ready to ship
- Plus 999,997,000 unit(s) shipping from 19 February 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Reel* |
|---|---|---|
| 1000 + | £1.33 | £1,330.00 |
*price indicative
- RS Stock No.:
- 226-0777
- Mfr. Part No.:
- FT5HNBPK20.0-T1
- Brand:
- Abracon
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Abracon | |
| Standard Frequency | 20MHz | |
| Mounting Type | Surface Mount | |
| Load Capacitance | 15pF | |
| Package Type | SMD | |
| Pin Count | 4 | |
| Dimensions | 5 x 3.2 x 1.5mm | |
| Frequency Tolerance | ±2.5ppm | |
Select all | ||
|---|---|---|
Brand Abracon | ||
Standard Frequency 20MHz | ||
Mounting Type Surface Mount | ||
Load Capacitance 15pF | ||
Package Type SMD | ||
Pin Count 4 | ||
Dimensions 5 x 3.2 x 1.5mm | ||
Frequency Tolerance ±2.5ppm | ||
The Abracon TCXO crystal has 20 MHz standard frequency and ± 2.5 ppm frequency tolerance. It is surface mount and has 5 x 3.2 x 1.5 mm dimension. It is lead(Pb) free and has -30°C to 85°C temperature.
It is RoHS/RoHS II compliant
