Wurth Elektronik 25 MHz Crystal ±20.00 ppm SMT 4-Pin 2.5 mm 3.2 mm 2.5mm
- RS Stock No.:
- 197-611
- Mfr. Part No.:
- 830063321
- Brand:
- Wurth Elektronik
Bulk discount available
Subtotal (1 tape of 10 units)*
£5.35
(exc. VAT)
£6.42
(inc. VAT)
FREE delivery for orders over £60.00
In Stock
- 2,600 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Tape* |
|---|---|---|
| 10 - 90 | £0.535 | £5.35 |
| 100 - 240 | £0.508 | £5.08 |
| 250 - 490 | £0.47 | £4.70 |
| 500 - 990 | £0.433 | £4.33 |
| 1000 + | £0.418 | £4.18 |
*price indicative
- RS Stock No.:
- 197-611
- Mfr. Part No.:
- 830063321
- Brand:
- Wurth Elektronik
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Wurth Elektronik | |
| Standard Frequency | 25MHz | |
| Product Type | Crystal | |
| Mount Type | Surface Mount | |
| Load Capacitance | 18pF | |
| Package Type | SMT | |
| Packaging | Tape & Reel | |
| Pin Count | 4 | |
| Length | 3.2mm | |
| Width | 2.5mm | |
| Height | 2.5mm | |
| Frequency Tolerance | ±20.00 ppm | |
| Frequency Stability | ±50 ppm | |
| Minimum Operating Temperature | -40.00°C | |
| Series Resistance | 50Ω | |
| Maximum Operating Temperature | 85.00°C | |
| Series | CFPX-180 | |
| Standards/Approvals | RoHS | |
| Automotive Standard | No | |
| Select all | ||
|---|---|---|
Brand Wurth Elektronik | ||
Standard Frequency 25MHz | ||
Product Type Crystal | ||
Mount Type Surface Mount | ||
Load Capacitance 18pF | ||
Package Type SMT | ||
Packaging Tape & Reel | ||
Pin Count 4 | ||
Length 3.2mm | ||
Width 2.5mm | ||
Height 2.5mm | ||
Frequency Tolerance ±20.00 ppm | ||
Frequency Stability ±50 ppm | ||
Minimum Operating Temperature -40.00°C | ||
Series Resistance 50Ω | ||
Maximum Operating Temperature 85.00°C | ||
Series CFPX-180 | ||
Standards/Approvals RoHS | ||
Automotive Standard No | ||
- COO (Country of Origin):
- CN
The Wurth Elektronik Standard 3.2 x 2.5mm SMD Crystal is expertly designed for high performance applications, featuring a robust ceramic package with a seam sealed metal LID that ensures durability. This crystal resonates at a frequency of 25.0MHz, making it an Ideal choice for diverse electronic circuits. The hermetically sealed design offers excellent protection against environmental factors, while its Compact size allows for seamless integration into various devices.
Manufactured with RoHS compliant materials for eco friendly applications
Resistant to environmental stresses which ensuring longevity and reliability
Complies with military standards for shock and vibration resilience
Designed to meet diverse operational temperature ranges for versatile applications
Offers straightforward reflow processing for efficient assembly
Provides a consistent performance through its carefully tailored electrical parameters
