Wurth Elektronik 25 MHz Crystal ±30.00 ppm SMT 4-Pin 2.5 mm 3.2 mm 2.5 mm
- RS Stock No.:
- 197-588
- Mfr. Part No.:
- 830105863709
- Brand:
- Wurth Elektronik
Bulk discount available
Subtotal (1 tape of 10 units)*
£5.35
(exc. VAT)
£6.42
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- 2,990 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Tape* |
|---|---|---|
| 10 - 90 | £0.535 | £5.35 |
| 100 - 240 | £0.508 | £5.08 |
| 250 - 490 | £0.47 | £4.70 |
| 500 - 990 | £0.433 | £4.33 |
| 1000 + | £0.418 | £4.18 |
*price indicative
- RS Stock No.:
- 197-588
- Mfr. Part No.:
- 830105863709
- Brand:
- Wurth Elektronik
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Wurth Elektronik | |
| Standard Frequency | 25MHz | |
| Product Type | Crystal | |
| Mount Type | Surface Mount | |
| Load Capacitance | 12pF | |
| Packaging | Tape & Reel | |
| Package Type | SMT | |
| Pin Count | 4 | |
| Length | 3.2mm | |
| Width | 2.5 mm | |
| Height | 2.5mm | |
| Frequency Tolerance | ±30.00 ppm | |
| Minimum Operating Temperature | -40.00°C | |
| Frequency Stability | ±30 ppm | |
| Series Resistance | 50Ω | |
| Maximum Operating Temperature | 85.00°C | |
| Series | CFPX-180 | |
| Standards/Approvals | RoHS, MIL-STD-202F, REACH | |
| Automotive Standard | No | |
| Select all | ||
|---|---|---|
Brand Wurth Elektronik | ||
Standard Frequency 25MHz | ||
Product Type Crystal | ||
Mount Type Surface Mount | ||
Load Capacitance 12pF | ||
Packaging Tape & Reel | ||
Package Type SMT | ||
Pin Count 4 | ||
Length 3.2mm | ||
Width 2.5 mm | ||
Height 2.5mm | ||
Frequency Tolerance ±30.00 ppm | ||
Minimum Operating Temperature -40.00°C | ||
Frequency Stability ±30 ppm | ||
Series Resistance 50Ω | ||
Maximum Operating Temperature 85.00°C | ||
Series CFPX-180 | ||
Standards/Approvals RoHS, MIL-STD-202F, REACH | ||
Automotive Standard No | ||
- COO (Country of Origin):
- CN
The Wurth Elektronik Standard 3.2 x 2.5mm SMD crystal is designed for a variety of applications, boasting a robust ceramic package with a hermetically sealed metal LID that ensures reliable performance even in challenging environments. Designed with the latest technology, it provides a frequency of 25.0MHz, ensuring consistency for high performance electronic devices. Compliance with RoHS ensures its suitability for environmentally conscious projects, further soLIDifying its presence as a go to component among engineers.
Frequency stability ensures accurate performance across varying conditions
Versatile operating temperature range supports diverse applications
Designed to comply with RoHS for environmental safety
Manufactured to withstand rigorous shock and vibration tests
Efficient load capacitance contributes to lower power consumption
Available in tape and reel packaging for streamlined assembly
