Wurth Elektronik 25 MHz Crystal ±10.00 ppm SMT 4-Pin 2.5 mm 3.2 mm 2.5mm
- RS Stock No.:
- 197-576
- Mfr. Part No.:
- 830108174209
- Brand:
- Wurth Elektronik
Subtotal (1 reel of 3000 units)*
£909.00
(exc. VAT)
£1,092.00
(inc. VAT)
FREE delivery for orders over £60.00
Temporarily out of stock
- Shipping from 27 July 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Reel* |
|---|---|---|
| 3000 + | £0.303 | £909.00 |
*price indicative
- RS Stock No.:
- 197-576
- Mfr. Part No.:
- 830108174209
- Brand:
- Wurth Elektronik
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Wurth Elektronik | |
| Standard Frequency | 25MHz | |
| Product Type | Crystal | |
| Mount Type | Surface Mount | |
| Load Capacitance | 10pF | |
| Package Type | SMT | |
| Packaging | Tape & Reel | |
| Pin Count | 4 | |
| Length | 3.2mm | |
| Width | 2.5mm | |
| Height | 2.5mm | |
| Frequency Tolerance | ±10.00 ppm | |
| Minimum Operating Temperature | -40.00°C | |
| Frequency Stability | ±15 ppm | |
| Maximum Operating Temperature | 85.00°C | |
| Series Resistance | 50Ω | |
| Standards/Approvals | MIL-STD-202F, REACH, RoHS | |
| Series | CFPX-180 | |
| Automotive Standard | No | |
| Select all | ||
|---|---|---|
Brand Wurth Elektronik | ||
Standard Frequency 25MHz | ||
Product Type Crystal | ||
Mount Type Surface Mount | ||
Load Capacitance 10pF | ||
Package Type SMT | ||
Packaging Tape & Reel | ||
Pin Count 4 | ||
Length 3.2mm | ||
Width 2.5mm | ||
Height 2.5mm | ||
Frequency Tolerance ±10.00 ppm | ||
Minimum Operating Temperature -40.00°C | ||
Frequency Stability ±15 ppm | ||
Maximum Operating Temperature 85.00°C | ||
Series Resistance 50Ω | ||
Standards/Approvals MIL-STD-202F, REACH, RoHS | ||
Series CFPX-180 | ||
Automotive Standard No | ||
- COO (Country of Origin):
- CN
The Wurth Elektronik Standard 3.2 x 2.5mm SMD quartz crystal is designed for use in a diverse range of electronics applications. With a ceramic package and a hermetically sealed metal lid, this component ensures long lasting reliability and excellent performance. Built for precision, it boasts a frequency of 25.0MHz, MADE to meet the demands of modern circuitry while remaining compliant with RoHS standards. The product is equipped with features such as exceptional frequency stability, allowing it to maintain performance under varying conditions.
Hermetically sealed for protection against moisture and external contaminants
Compliant with industry standards promoting a sustainable choice for manufacturers
Efficient packaging simplifies logistics and inventory management
Robust construction withstands mechanical stress and vibrations
Stable performance with minimal drift over time ensures reliability in critical applications
