Wurth Elektronik 16 MHz Crystal ±20 ppm SMT 4-Pin 0.6 mm 2.5 mm 2mm
- RS Stock No.:
- 197-525
- Mfr. Part No.:
- 830069392
- Brand:
- Wurth Elektronik
Subtotal (1 reel of 3000 units)*
£981.00
(exc. VAT)
£1,176.00
(inc. VAT)
FREE delivery for orders over £60.00
Temporarily out of stock
- Shipping from 17 June 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Reel* |
|---|---|---|
| 3000 + | £0.327 | £981.00 |
*price indicative
- RS Stock No.:
- 197-525
- Mfr. Part No.:
- 830069392
- Brand:
- Wurth Elektronik
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Wurth Elektronik | |
| Product Type | Crystal | |
| Standard Frequency | 16MHz | |
| Mount Type | Surface Mount | |
| Load Capacitance | 10pF | |
| Packaging | Tape & Reel | |
| Package Type | SMT | |
| Pin Count | 4 | |
| Length | 2.5mm | |
| Width | 2mm | |
| Height | 0.6mm | |
| Frequency Tolerance | ±20 ppm | |
| Frequency Stability | ±20 ppm | |
| Minimum Operating Temperature | -40°C | |
| Maximum Operating Temperature | 85°C | |
| Series Resistance | 100Ω | |
| Series | CFPX-218 | |
| Standards/Approvals | REACH, RoHS | |
| Automotive Standard | No | |
| Select all | ||
|---|---|---|
Brand Wurth Elektronik | ||
Product Type Crystal | ||
Standard Frequency 16MHz | ||
Mount Type Surface Mount | ||
Load Capacitance 10pF | ||
Packaging Tape & Reel | ||
Package Type SMT | ||
Pin Count 4 | ||
Length 2.5mm | ||
Width 2mm | ||
Height 0.6mm | ||
Frequency Tolerance ±20 ppm | ||
Frequency Stability ±20 ppm | ||
Minimum Operating Temperature -40°C | ||
Maximum Operating Temperature 85°C | ||
Series Resistance 100Ω | ||
Series CFPX-218 | ||
Standards/Approvals REACH, RoHS | ||
Automotive Standard No | ||
- COO (Country of Origin):
- CN
The Wurth Elektronik SMD crystal encapsulates cutting edge technology within a hermetically sealed ceramic package. Designed for optimal performance, it boasts a robust seam sealed metal LID that enhances durability and reliability in various environmental conditions. The product is tailored for precision applications requiring stable frequency characteristics and adherence to strict tolerance levels.
Minimal ageing ensures dependable performance over time Ideal for long term projects
Low drive level maximizes energy efficiency making it environmentally friendly
Compliant with international standards including RoHS indicating commitment to sustainability
Housed in a user friendly reel pack for efficient handling and integration into production lines
Capable of withstanding rigorous vibration and shock tests
