Wurth Elektronik 16.384 MHz Crystal ±20 ppm SMT 4-Pin 0.6 mm 2.5 mm 2 mm
- RS Stock No.:
- 197-524
- Mfr. Part No.:
- 830069395
- Brand:
- Wurth Elektronik
Bulk discount available
Subtotal (1 tape of 10 units)*
£5.62
(exc. VAT)
£6.74
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- 3,000 unit(s) shipping from 02 March 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Tape* |
|---|---|---|
| 10 - 90 | £0.562 | £5.62 |
| 100 - 240 | £0.534 | £5.34 |
| 250 - 490 | £0.495 | £4.95 |
| 500 - 990 | £0.455 | £4.55 |
| 1000 + | £0.438 | £4.38 |
*price indicative
- RS Stock No.:
- 197-524
- Mfr. Part No.:
- 830069395
- Brand:
- Wurth Elektronik
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Wurth Elektronik | |
| Standard Frequency | 16.384MHz | |
| Product Type | Crystal | |
| Mount Type | Surface Mount | |
| Load Capacitance | 10pF | |
| Package Type | SMT | |
| Packaging | Tape & Reel | |
| Pin Count | 4 | |
| Length | 2.5mm | |
| Width | 2 mm | |
| Height | 0.6mm | |
| Frequency Tolerance | ±20 ppm | |
| Minimum Operating Temperature | -40°C | |
| Frequency Stability | ±20 ppm | |
| Series Resistance | 100Ω | |
| Maximum Operating Temperature | 85°C | |
| Standards/Approvals | REACH, RoHS | |
| Series | CFPX-218 | |
| Automotive Standard | No | |
| Select all | ||
|---|---|---|
Brand Wurth Elektronik | ||
Standard Frequency 16.384MHz | ||
Product Type Crystal | ||
Mount Type Surface Mount | ||
Load Capacitance 10pF | ||
Package Type SMT | ||
Packaging Tape & Reel | ||
Pin Count 4 | ||
Length 2.5mm | ||
Width 2 mm | ||
Height 0.6mm | ||
Frequency Tolerance ±20 ppm | ||
Minimum Operating Temperature -40°C | ||
Frequency Stability ±20 ppm | ||
Series Resistance 100Ω | ||
Maximum Operating Temperature 85°C | ||
Standards/Approvals REACH, RoHS | ||
Series CFPX-218 | ||
Automotive Standard No | ||
- COO (Country of Origin):
- CN
The Wurth Elektronik 2.5 x 2mm SMD crystal exemplifies precision engineering, featuring a hermetically sealed ceramic package with a Durable seam sealed metal lid. Designed meticulously for optimal performance, this crystal operates at a frequency of 16.3840MHz, making it Ideal for a wide range of applications that require reliable timekeeping and frequency stability.
High frequency accuracy ensures superior performance in timing applications
Operating temperature range accommodates diverse climatic conditions for versatile use
Compliant with RoHS ensures environmentally friendly applications
Lightweight construction reduces overall product weight enhancing portability
