Wurth Elektronik 25 MHz Crystal ±10 ppm SMT 4-Pin 0.6 mm 2.5 mm 2 mm
- RS Stock No.:
- 197-512
- Mfr. Part No.:
- 830107871909
- Brand:
- Wurth Elektronik
Bulk discount available
Subtotal (1 tape of 10 units)*
£4.37
(exc. VAT)
£5.24
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- 3,000 unit(s) shipping from 02 March 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Tape* |
|---|---|---|
| 10 - 90 | £0.437 | £4.37 |
| 100 - 240 | £0.415 | £4.15 |
| 250 - 490 | £0.385 | £3.85 |
| 500 - 990 | £0.354 | £3.54 |
| 1000 + | £0.35 | £3.50 |
*price indicative
- RS Stock No.:
- 197-512
- Mfr. Part No.:
- 830107871909
- Brand:
- Wurth Elektronik
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Wurth Elektronik | |
| Product Type | Crystal | |
| Standard Frequency | 25MHz | |
| Mount Type | Surface Mount | |
| Load Capacitance | 10pF | |
| Package Type | SMT | |
| Packaging | Tape & Reel | |
| Pin Count | 4 | |
| Length | 2.5mm | |
| Width | 2 mm | |
| Height | 0.6mm | |
| Frequency Tolerance | ±10 ppm | |
| Minimum Operating Temperature | -20°C | |
| Frequency Stability | ±10 ppm | |
| Series Resistance | 100Ω | |
| Maximum Operating Temperature | 70°C | |
| Series | CFPX-218 | |
| Standards/Approvals | REACH, RoHS | |
| Automotive Standard | No | |
| Select all | ||
|---|---|---|
Brand Wurth Elektronik | ||
Product Type Crystal | ||
Standard Frequency 25MHz | ||
Mount Type Surface Mount | ||
Load Capacitance 10pF | ||
Package Type SMT | ||
Packaging Tape & Reel | ||
Pin Count 4 | ||
Length 2.5mm | ||
Width 2 mm | ||
Height 0.6mm | ||
Frequency Tolerance ±10 ppm | ||
Minimum Operating Temperature -20°C | ||
Frequency Stability ±10 ppm | ||
Series Resistance 100Ω | ||
Maximum Operating Temperature 70°C | ||
Series CFPX-218 | ||
Standards/Approvals REACH, RoHS | ||
Automotive Standard No | ||
- COO (Country of Origin):
- CN
The Wurth Elektronik 2.5 x 2mm SMD crystal is designed for optimal performance within a hermetically sealed ceramic package. Built with a seam sealed metal lid, it ensures durability and reliability in challenging environments. Operating at a frequency of 25.0MHz, this component excels in applications demanding precision timing and stability. The crystal is crafted to withstand rigorous conditions, featuring MIL STD 883F compliant vibration testing and is fully RoHS compliant, showcasing a commitment to environmental safety.
Optimized for precision timing in electronic applications
Excellent frequency stability ensures consistent performance
SMD form factor allows for easy integration in Compact designs
Rigorous testing standards guarantee reliability under various conditions
Fully compliant with RoHS regulations promotes environmental responsibility
