RS PRO Control Cable, 18 Cores, 1 mm², CY, Screened, 50m, Grey PVC Sheath, 17 AWG
- RS Stock No.:
- 827-4199
- Distrelec Article No.:
- 300-49-546
- Brand:
- RS PRO
Subtotal (1 reel of 50 metres)*
£446.99
(exc. VAT)
£536.39
(inc. VAT)
FREE delivery for orders over £50.00
- 5 unit(s) shipping from 28 November 2025
Reel(s) | Per Reel | Per Metre* |
---|---|---|
1 + | £446.99 | £8.94 |
*price indicative
- RS Stock No.:
- 827-4199
- Distrelec Article No.:
- 300-49-546
- Brand:
- RS PRO
Select all | Attribute | Value |
---|---|---|
Brand | RS PRO | |
Series | ÖLFLEX® CLASSIC 115 CY | |
Number of Cores | 18 | |
Cross Sectional Area | 1 mm² | |
American Wire Gauge | 17 AWG | |
Conductor Material | Copper | |
Sheath Material | PVC | |
Sheath Colour | Grey | |
Control Cable Type | CY | |
Screened/Unscreened | Screened | |
Screen Type | Braid | |
Outer Diameter | 13.9mm | |
Length | 50m | |
Minimum Bend Radius | Fixed - 6 x D Occasional Flexing - 20 x D | |
Voltage Rating | 300/500 V | |
Current Rating | 15 A | |
CPR Certification | Eca | |
Standards Met | EN 50525-2-51 | |
Fire Behaviour | Flame Retardant | |
Maximum Operating Temperature | +80°C | |
Minimum Operating Temperature | -40°C | |
Core Strands | 32/0.2 mm | |
Insulation Material | PVC | |
Cable Shape | Multicore | |
Filler Material | Non-Wicking Filler | |
Conductor Resistance | 19.5 Ω/km | |
Oil Resistant | Yes | |
Earth Cable | Yes | |
Select all | ||
---|---|---|
Brand RS PRO | ||
Series ÖLFLEX® CLASSIC 115 CY | ||
Number of Cores 18 | ||
Cross Sectional Area 1 mm² | ||
American Wire Gauge 17 AWG | ||
Conductor Material Copper | ||
Sheath Material PVC | ||
Sheath Colour Grey | ||
Control Cable Type CY | ||
Screened/Unscreened Screened | ||
Screen Type Braid | ||
Outer Diameter 13.9mm | ||
Length 50m | ||
Minimum Bend Radius Fixed - 6 x D Occasional Flexing - 20 x D | ||
Voltage Rating 300/500 V | ||
Current Rating 15 A | ||
CPR Certification Eca | ||
Standards Met EN 50525-2-51 | ||
Fire Behaviour Flame Retardant | ||
Maximum Operating Temperature +80°C | ||
Minimum Operating Temperature -40°C | ||
Core Strands 32/0.2 mm | ||
Insulation Material PVC | ||
Cable Shape Multicore | ||
Filler Material Non-Wicking Filler | ||
Conductor Resistance 19.5 Ω/km | ||
Oil Resistant Yes | ||
Earth Cable Yes | ||
- COO (Country of Origin):
- DE
LAPP ÖLFLEX® CLASSIC 115 CY Series Control Cable, 18 Cores, 1 mm² Cross Sectional Area - 1136218
Features & Benefits
• Flexible copper conductors enhance installation versatility
• Minimum bend radius allows for tight installation spaces
• Flame retardant properties improve safety in operational settings
Applications
• Suitable for conveyor and transport systems integration
• Effective in heating and air conditioning systems
What is the significance of the screened design in this cable?
How does the flame retardant feature enhance safety?
What are the implications of the minimum bend radius?
What makes this cable a good choice for industrial settings?
