RS PRO Control Cable, 7 Cores, 2.5 mm², CY, Screened, 50m, Grey PVC Sheath, 13 AWG
- RS Stock No.:
- 827-4173
- Brand:
- RS PRO
Subtotal (1 reel of 50 metres)*
£371.30
(exc. VAT)
£445.56
(inc. VAT)
FREE delivery for orders over £50.00
- 21 unit(s) ready to ship
- Plus 2 unit(s) ready to ship from another location
- Plus 5 unit(s) shipping from 30 January 2026
Reel(s) | Per Reel | Per Metre* |
---|---|---|
1 + | £371.30 | £7.426 |
*price indicative
- RS Stock No.:
- 827-4173
- Brand:
- RS PRO
Select all | Attribute | Value |
---|---|---|
Brand | RS PRO | |
Number of Cores | 7 | |
Cross Sectional Area | 2.5 mm² | |
American Wire Gauge | 13 AWG | |
Conductor Material | Copper | |
Sheath Material | PVC | |
Control Cable Type | CY | |
Sheath Colour | Grey | |
Screened/Unscreened | Screened | |
Screen Type | Tinned Copper Braid | |
Minimum Bend Radius | Fixed - 6 x D Occasional Flexing - 20 x D | |
Length | 50m | |
Outer Diameter | 11.2mm | |
Voltage Rating | 300/500 V | |
Current Rating | 26 A | |
CPR Certification | Eca | |
Standards Met | IEC 60228 | |
Maximum Operating Temperature | +80°C | |
Fire Behaviour | Flame Retardant | |
Insulation Material | PVC | |
Cable Shape | Multicore | |
Oil Resistant | Yes | |
Minimum Operating Temperature | -40°C | |
Filler Material | Non-Wicking Filler | |
Conductor Resistance | 7.09 Ω/km | |
Earth Cable | Yes | |
Core Strands | 50/0.25 mm | |
Select all | ||
---|---|---|
Brand RS PRO | ||
Number of Cores 7 | ||
Cross Sectional Area 2.5 mm² | ||
American Wire Gauge 13 AWG | ||
Conductor Material Copper | ||
Sheath Material PVC | ||
Control Cable Type CY | ||
Sheath Colour Grey | ||
Screened/Unscreened Screened | ||
Screen Type Tinned Copper Braid | ||
Minimum Bend Radius Fixed - 6 x D Occasional Flexing - 20 x D | ||
Length 50m | ||
Outer Diameter 11.2mm | ||
Voltage Rating 300/500 V | ||
Current Rating 26 A | ||
CPR Certification Eca | ||
Standards Met IEC 60228 | ||
Maximum Operating Temperature +80°C | ||
Fire Behaviour Flame Retardant | ||
Insulation Material PVC | ||
Cable Shape Multicore | ||
Oil Resistant Yes | ||
Minimum Operating Temperature -40°C | ||
Filler Material Non-Wicking Filler | ||
Conductor Resistance 7.09 Ω/km | ||
Earth Cable Yes | ||
Core Strands 50/0.25 mm | ||
- COO (Country of Origin):
- DE
LAPP Control Cable, 7 Cores, 2.5 mm² Cross Sectional Area - 38101598
Features & Benefits
• Flame retardant properties enhance safety in installations
• Operating temperature range from -40°C to +80°C supports versatility
• Flexible design allows for easy routing and installation
• Tinned copper braid ensures strong shielding against environmental factors
Applications
• Ideal for use in electrical installations in machinery
• Suitable for connections in mechanical equipment requiring flexibility
• Effective in environments where flame retardant materials are necessary
• Effective for powering control circuits in industrial
What is the conductor material and why is it important?
How does the cable's sheath material contribute to its durability?
What flexibility does this cable offer compared to standard cables?
What factors influence the maximum operating temperature of this cable?
Note
