Lapp ÖLFLEX CLASSIC 130 Control Cable, 2 Cores, 1 mm², YY, Unscreened, 100m, Grey LSZH Sheath, 18 AWG

View all Control Cable

Subtotal (1 reel of 100 metres)*

£156.19

(exc. VAT)

£187.43

(inc. VAT)

Add to Basket
Select or type quantity
In Stock
  • 12 unit(s) ready to ship
  • Plus 5 unit(s) shipping from 14 November 2025
  • Plus 7 unit(s) shipping from 05 December 2025
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Reel(s)
Per Reel
Per Metre*
1 +£156.19£1.562

*price indicative

RS Stock No.:
819-9565
Distrelec Article No.:
301-80-468
Mfr. Part No.:
1123066
Brand:
Lapp
Find similar products by selecting one or more attributes.
Select all

Brand

Lapp

Series

ÖLFLEX CLASSIC 130

Number of Cores

2

Cross Sectional Area

1 mm²

American Wire Gauge

18 AWG

Conductor Material

Bare Copper

Sheath Material

LSZH

Sheath Colour

Grey

Control Cable Type

YY

Screened/Unscreened

Unscreened

Screen Type

Unscreened

Length

100m

Minimum Bend Radius

4 x Diameter

Outer Diameter

5.7mm

Voltage Rating

500 V

CPR Certification

Dca

Standards Met

CE, RoHS, UL

Fire Behaviour

Flame Retardant, Low Smoke Zero Halogen (LSZH)

Maximum Operating Temperature

+80°C

Insulation Material

Zero Halogen

Oil Resistant

No

Minimum Operating Temperature

-40°C

Drain Wire

Yes

COO (Country of Origin):
DE

LAPP Multicore Cable, 2 Cores, 1mm² CSA - ÖLFLEX Series - 1123066


Transmit data,signals and power easily with this multicore control cable from LAPP. It has LSZH fire behaviour, so it emits minimal smoke and no toxic fumes in the event of a fire for enhanced workplace safety. Thanks to bare copper cores, you can be sure of reliably high conductivity. The PVC-based sheath is resistant to moisture and wear, making it suitable for use in harsh indoor and outdoor applications. It's an unscreened cable, so it's flexible enough for installation in tight spaces.

Features & Benefits


• Wide operating temperature range between -40°C and +80°C for safe use in demanding conditions
• 100m length for long runs or multiple cut-and-fix applications
• Grey colour for ease of identification in a colour-coded setup

Applications


• Studio cabling
• Production lines
• HVAC systems

Can I use this control cable for conductive applications?


No, this 2-core cable is designed for non-conductive applications. For conductive installations, use LAPP's 3-core cable (141-277).
