Lapp ÖLFLEX CLASSIC 110 Control Cable, 41 Cores, 1 mm², YY, Unscreened, 50m, Grey PVC Sheath, 17 AWG

RS Stock No.:: 686-0697
Distrelec Article No.:: 304-01-044
Mfr. Part No.:: 1119241
Brand:: Lapp

Lapp ÖLFLEX CLASSIC 110 Control Cable, 41 Cores, 1 mm², YY, Unscreened, 50m, Grey PVC Sheath, 17 AWG

Subtotal (1 reel of 50 metres)*

£717.00

(exc. VAT)

£860.40

(inc. VAT)

FREE delivery for orders over £50.00

In Stock

3 unit(s) ready to ship

Need more? Click ‘Check delivery dates’ to find extra stock and lead times.

Reel(s)	Per Reel	Per Metre*
1 +	£717.00	£14.34

*price indicative

Shop our LAPP Glands

Ensure optimal performance and protection for your LAPP cable by pairing it with genuine LAPP cable glands. Engineered for a perfect fit, these glands provide secure strain relief, reliable sealing, and long-lasting durability—even in demanding industrial environments.

Shop here

RS Stock No.:: 686-0697
Distrelec Article No.:: 304-01-044
Mfr. Part No.:: 1119241
Brand:: Lapp

Specifications

Technical Reference

Legislation and Compliance

Product Details

Find similar products by selecting one or more attributes.

Select all	Attribute	Value
	Brand	Lapp
	Series	ÖLFLEX CLASSIC 110
	Number of Cores	41
	Cross Sectional Area	1 mm²
	American Wire Gauge	17 AWG
	Conductor Material	Copper
	Sheath Material	PVC
	Sheath Colour	Grey
	Control Cable Type	YY
	Screened/Unscreened	Unscreened
	Outer Diameter	18.8mm
	Length	50m
	Minimum Bend Radius	Fixed - 4 x D Occasional flexing - 10 x D
	Voltage Rating	300/500 V
	Current Rating	15 A
	Standards Met	CE
	CPR Certification	Eca
	Maximum Operating Temperature	+80°C
	Oil Resistant	Yes
	Core Strands	32/0.2 mm
	Minimum Operating Temperature	-40°C
	Filler Material	Non-Wicking Filler
	Conductor Resistance	19.5 Ω/km
	Insulation Material	PVC
	Earth Cable	Yes

	Select all
	Brand Lapp
	Series ÖLFLEX CLASSIC 110
	Number of Cores 41
	Cross Sectional Area 1 mm²
	American Wire Gauge 17 AWG
	Conductor Material Copper
	Sheath Material PVC
	Sheath Colour Grey
	Control Cable Type YY
	Screened/Unscreened Unscreened
	Outer Diameter 18.8mm
	Length 50m
	Minimum Bend Radius Fixed - 4 x D Occasional flexing - 10 x D
	Voltage Rating 300/500 V
	Current Rating 15 A
	Standards Met CE
	CPR Certification Eca
	Maximum Operating Temperature +80°C
	Oil Resistant Yes
	Core Strands 32/0.2 mm
	Minimum Operating Temperature -40°C
	Filler Material Non-Wicking Filler
	Conductor Resistance 19.5 Ω/km
	Insulation Material PVC
	Earth Cable Yes

COO (Country of Origin):: DE

LAPP Multicore Control Cable, 41 Cores, 50m Length - ÖLFLEX Series - 1119241

To complete complex wiring tasks with just one cable, choose this multicore control cable from LAPP. Its 41 conductor cores let you connect multiple appliances to your control system at once, minimising wiring bulk. As it features bare copper conductors, the cable efficiently transfers instructions to your machines to support reliable automated performance. A PVC jacket withstands heat, oil and chemical damage, making this a durable option for use in harsh conditions.

Features & Benefits

• Stranded conductor cores provide increased flexibility for versatile installation
• Non-wicking filler material repels moisture to protect against corrosion
• 15A current rating indicates the wire easily handles large electrical loads
• Cross-sectional area of 1mm² to fit into compact equipment

Applications

• Wind turbines
• Processing plants
• Packaging industry

Does this control cable have an earth wire?

Yes, this multicore cable includes an integral earth connection for added electrical safety.
