Igus chainflex CF9 Control Cable, 4 Cores, 1 mm², YY, Unscreened, 10m, Blue, 17 AWG

View all Control Cable
Currently unavailable
Sorry, we don't know when this will be back in stock.
RS Stock No.:
502-3165
Mfr. Part No.:
CF9.10.04
Brand:
Igus
Find similar products by selecting one or more attributes.
Select all

Brand

Igus

Series

chainflex CF9

Number of Cores

4

Cross Sectional Area

1 mm²

American Wire Gauge

17 AWG

Conductor Material

Bare Copper

Control Cable Type

YY

Sheath Colour

Blue

Screened/Unscreened

Unscreened

Screen Type

Unscreened

Outer Diameter

6.5mm

Length

10m

Minimum Bend Radius

5 x Diameter

Voltage Rating

300 V

Maximum Operating Temperature

+100°C

Drain Wire

No

Insulation Material

TPE

Minimum Operating Temperature

-35°C

RoHS Status: Exempt

COO (Country of Origin):
JP

300 / 500 V CF9 control cable


Igus CF9 Chainflex control cable for heavy duty applications. Chainflex cables have been designed for durability and to reduce downtime due to cable failure.

Features and Benefits


Ultra-flexible control cable for unshielded cable chains used in various applications
PVC-free and halogen free
Excellent ultraviolet resistance, wear resistance, and oil resistance
The sheath forms a high-pressure extrusion that bites the gaps
Can also be used outdoors for processing machines, cranes, and low-temperature refrigeration, etc.

Standards

Conforms to CE and VDE
