Igus chainflex CF9 Control Cable, 7 Cores, 1.5 mm², Unscreened, 10m, Blue TPE Sheath

View all Control Cable

Subtotal (1 bag of 10 metres)*

£114.04

(exc. VAT)

£136.85

(inc. VAT)

Add to Basket
Select or type quantity
In Stock
  • Plus 10 unit(s) shipping from 27 October 2025
  • Plus 30 unit(s) shipping from 31 October 2025
  • Plus 999,999,950 unit(s) shipping from 17 November 2025
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units
Per unit
Per Bag*
10 +£11.404£114.04

*price indicative

RS Stock No.:
210-0495
Mfr. Part No.:
CF9.15.07 (10m)
Brand:
Igus
Find similar products by selecting one or more attributes.
Select all

Brand

Igus

Series

chainflex CF9

Number of Cores

7

Cross Sectional Area

1.5 mm²

Conductor Material

Bare Copper

Sheath Material

TPE

Sheath Colour

Blue

Screened/Unscreened

Unscreened

Length

10m

Outer Diameter

7.5mm

Minimum Bend Radius

e-chain® linear minimum 5 x D, flexible minimum 4 x D, fixed minimum 3 x D

Voltage Rating

300/500 V

Current Rating

21 A

Maximum Operating Temperature

+100°C

Fire Behaviour

Halogen Free

Insulation Material

TPE

Minimum Operating Temperature

-55°C

Oil Resistant

Yes

COO (Country of Origin):
DE
The Igus chainflex cables from igus are designed with one message in mind, “cost down, life up”. With our TPE jacket material, we provide products that can cope with highly demanding applications adopting very high abrasion resistance whilst providing excellent protection levels when faced with harsh chemical and oil-based environments. Our patented bundle design ensures small bend radius figures which make chainflex cables ideal for use in echain (cable carrier), flexible and fixed applications.

Small bend radii, ideal for space saving installation
Patented core bundled design to ensure long lasting lifetime in dynamic applications
Oil resistant Class 4 which supports almost unlimited oil + bio-oil resistance
Low angled braided screen optimised for use in continuous flexing applications
300/500v rated for use in control cable applications
Wide temperature ranges from -55°c to +100°c depending on application type
Guaranteed service life for use in echains, minimise risk of unplanned downtime
Long travel rated for reliable use up to 400m in echains®

Unscreened control cables are used in a wide variety of applications where EMC/EMI/Cross talk is not an issue. Core sizes range from 0.25mm²-16mm², with core identification using DIN 47100 colour coding or with black cores, white numerals + earth (GY) depending on the size of core required.CF9 is designed for heavy duty applications supported by its almost unlimited resistance to oil and bio-oils. Ideal for use on indoor and outdoor applications, supported by a working temperature range from -55°C to up +100°C. Typical application areas include

storage and retrieval units, machining units/machine tools, quick handling, clean room, semiconductor insertion, outdoor cranes, low temperature applications.

High UV resistance.
Oil-resistant (following DIN EN 60811-404).
Bio-oil resistant (following VDMA 24568)
Halogen-free (Following DIN EN 60754)
Silicone-free following PV 3.10.7 – status 1992.
ROHS-II (Lead-free) following 2011/65/EC.
Clean room according to ISO Class 1.
CE following 2014/35/EU.

Note
chainflex® guarantee, now verified by UL - all igus flexible cables are thoroughly tested in our 2,750m laboratory with reliable specialist equipment where we have over 600 tests running simultaneously, to confidently provide our 36-month guarantee.
