Lapp ÖLFLEX 150 Control Cable, 4 Cores, 2.5 mm², Unscreened, 50m, Grey PVC Sheath, 14 AWG
- RS Stock No.:
- 444-0913
- Distrelec Article No.:
- 304-03-720
- Mfr. Part No.:
- 0015404
- Brand:
- Lapp
Subtotal (1 reel of 50 metres)*
£257.92
(exc. VAT)
£309.50
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- 3 unit(s) ready to ship
- Plus 6 unit(s) shipping from 09 January 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Reel(s) | Per Reel | Per Metre* |
|---|---|---|
| 1 + | £257.92 | £5.158 |
*price indicative
- RS Stock No.:
- 444-0913
- Distrelec Article No.:
- 304-03-720
- Mfr. Part No.:
- 0015404
- Brand:
- Lapp
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Lapp | |
| Series | ÖLFLEX 150 | |
| Number of Cores | 4 | |
| Cross Sectional Area | 2.5 mm² | |
| American Wire Gauge | 14 AWG | |
| Conductor Material | Copper | |
| Sheath Material | PVC | |
| Sheath Colour | Grey | |
| Screened/Unscreened | Unscreened | |
| Screen Type | Unscreened | |
| Length | 50m | |
| Minimum Bend Radius | 4 x Diameter | |
| Outer Diameter | 10.8mm | |
| Voltage Rating | 500 V | |
| CPR Certification | Eca | |
| Standards Met | CE, CSA, UL | |
| Fire Behaviour | Flame Retardant | |
| Maximum Operating Temperature | +70°C | |
| Insulation Material | PVC | |
| Oil Resistant | Yes | |
| Drain Wire | Yes | |
| Minimum Operating Temperature | -40°C | |
| Select all | ||
|---|---|---|
Brand Lapp | ||
Series ÖLFLEX 150 | ||
Number of Cores 4 | ||
Cross Sectional Area 2.5 mm² | ||
American Wire Gauge 14 AWG | ||
Conductor Material Copper | ||
Sheath Material PVC | ||
Sheath Colour Grey | ||
Screened/Unscreened Unscreened | ||
Screen Type Unscreened | ||
Length 50m | ||
Minimum Bend Radius 4 x Diameter | ||
Outer Diameter 10.8mm | ||
Voltage Rating 500 V | ||
CPR Certification Eca | ||
Standards Met CE, CSA, UL | ||
Fire Behaviour Flame Retardant | ||
Maximum Operating Temperature +70°C | ||
Insulation Material PVC | ||
Oil Resistant Yes | ||
Drain Wire Yes | ||
Minimum Operating Temperature -40°C | ||
- COO (Country of Origin):
- DE
LAPP Control Cable, 500V Voltage Rating, 10.8mm Outer Diameter - ÖLFLEX series - 0015404
Install this 13AWG control cable from LAPP to support the optimal performance of your automated and instrumentation processes. It has a 4-core construction to simultaneously transfer power and data signals, so cuts down on your wiring needs. A robust PVC jacket resists damage from oils, chemicals and abrasion, so you can confidently use the cable in challenging wet and dry indoor settings. This material also insulates live wires to prevent electric shocks for improved workplace safety.
Features & Benefits
• Effective bend radius of 4 times the diameter for easy handling and installation
• Broad operating temperature range of -40°C to +70°C for use in tough industrial conditions
• Broad operating temperature range of -40°C to +70°C for use in tough industrial conditions
Applications
• Healthcare industry
• Computer systems
• Industrial packaging and assembly lines
• Food and beverage processing
• Computer systems
• Industrial packaging and assembly lines
• Food and beverage processing
Is this a fire-safe control cable?
This control cable has flame-retardant characteristics, which means it limits the spread of fires. This makes it a safe choice for your workplace.
Standards
VDE 0295, part 5/IEC60228 C1·5
