Belden C3GESY Control Cable, 3 Cores, 2.5 mm², SY, Screened, 50m, Grey PVC Sheath
- RS Stock No.:
- 176-2368
- Mfr. Part No.:
- C3GESY-KC50
- Brand:
- Belden
Subtotal (1 reel of 50 metres)*
£226.53
(exc. VAT)
£271.84
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- 2 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Reel(s) | Per Reel | Per Metre* |
---|---|---|
1 + | £226.53 | £4.531 |
*price indicative
- RS Stock No.:
- 176-2368
- Mfr. Part No.:
- C3GESY-KC50
- Brand:
- Belden
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
---|---|---|
Brand | Belden | |
Series | C3GESY | |
Number of Cores | 3 | |
Cross Sectional Area | 2.5 mm² | |
Conductor Material | Copper | |
Sheath Material | PVC | |
Sheath Colour | Grey | |
Control Cable Type | SY | |
Screen Type | Galvanised Steel Braid | |
Screened/Unscreened | Screened | |
Armoured | Yes | |
Outer Diameter | 12.6mm | |
Minimum Bend Radius | 20 x 12.6 (Occasional), 6 x 12.6 (Fixed) | |
Length | 50m | |
Voltage Rating | 450 V, 750 V | |
Fire Behaviour | Flame Retardant | |
Maximum Operating Temperature | +80°C | |
Cable Shape | Multicore | |
Oil Resistant | Yes | |
Minimum Operating Temperature | -40°C | |
Insulation Material | PVC | |
Earth Cable | Yes | |
Select all | ||
---|---|---|
Brand Belden | ||
Series C3GESY | ||
Number of Cores 3 | ||
Cross Sectional Area 2.5 mm² | ||
Conductor Material Copper | ||
Sheath Material PVC | ||
Sheath Colour Grey | ||
Control Cable Type SY | ||
Screen Type Galvanised Steel Braid | ||
Screened/Unscreened Screened | ||
Armoured Yes | ||
Outer Diameter 12.6mm | ||
Minimum Bend Radius 20 x 12.6 (Occasional), 6 x 12.6 (Fixed) | ||
Length 50m | ||
Voltage Rating 450 V, 750 V | ||
Fire Behaviour Flame Retardant | ||
Maximum Operating Temperature +80°C | ||
Cable Shape Multicore | ||
Oil Resistant Yes | ||
Minimum Operating Temperature -40°C | ||
Insulation Material PVC | ||
Earth Cable Yes | ||
- COO (Country of Origin):
- CN
Designed for applications which are installed in occasional flexing and fixed locations. Cable applicationsinclude precision controlsensors, multi axis control machines, temperature controllers, control panels, machine cutting tools, auxiliary equipment, motor speed control, production machinery and many more.
