Lapp Olflex Chain 809 Control Cable, 2 Cores, 0.5 mm² 21 AWG, Unscreened, Grey Polyvinyl Chloride Sheath
- RS Stock No.:
- 433-348
- Mfr. Part No.:
- 1026700
- Brand:
- Lapp
Subtotal (1 reel of 100 metres)*
£125.86
(exc. VAT)
£151.03
(inc. VAT)
FREE delivery for orders over £50.00
- 2 unit(s) ready to ship
Reel(s) | Per Reel | Per Metre* |
|---|---|---|
| 1 + | £125.86 | £1.259 |
*price indicative
- RS Stock No.:
- 433-348
- Mfr. Part No.:
- 1026700
- Brand:
- Lapp
Select all | Attribute | Value |
|---|---|---|
| Brand | Lapp | |
| Product Type | Control Cable | |
| Series | Olflex Chain 809 | |
| Number of Cores | 2 | |
| Conductor Material | Copper | |
| Jacket Material | Polyvinyl Chloride | |
| Jacket Colour | Grey | |
| Screened/Unscreened | Unscreened | |
| Conductor Type | Stranded | |
| Minimum Operating Temperature | -40°C | |
| Maximum Operating Temperature | 80°C | |
| Standards/Approvals | EN 50334, EN 50290-2-22, VD0293-1, UL VW-1, EN 13501-6, UL 758 AWM Styl20886, UL 1581 §1061, CSA FT1, CSA C22.2 No. 2556, CSA C22.2 No. 210, EN 50525-2-51, EN 50395, EN 50575, EN 50396, EN 60332-1-2, EN 60811, EU 2011/65/EU (RoHS), EU- 2014/35/EU, EU-Regution no. 305/2011 (CPR), IEC 60228, IEC 60332-1-2, IEC 60811, EN 60228 | |
| Hazardous Area Certification | No | |
| Cable CSA | 0.5 mm² | |
| Fire Behaviour | Flame Retardant acc. to IEC 60332-1-2 resp. EN 60332-1-2 | |
| American Wire Gauge | 21AWG | |
| Select all | ||
|---|---|---|
Brand Lapp | ||
Product Type Control Cable | ||
Series Olflex Chain 809 | ||
Number of Cores 2 | ||
Conductor Material Copper | ||
Jacket Material Polyvinyl Chloride | ||
Jacket Colour Grey | ||
Screened/Unscreened Unscreened | ||
Conductor Type Stranded | ||
Minimum Operating Temperature -40°C | ||
Maximum Operating Temperature 80°C | ||
Standards/Approvals EN 50334, EN 50290-2-22, VD0293-1, UL VW-1, EN 13501-6, UL 758 AWM Styl20886, UL 1581 §1061, CSA FT1, CSA C22.2 No. 2556, CSA C22.2 No. 210, EN 50525-2-51, EN 50395, EN 50575, EN 50396, EN 60332-1-2, EN 60811, EU 2011/65/EU (RoHS), EU- 2014/35/EU, EU-Regution no. 305/2011 (CPR), IEC 60228, IEC 60332-1-2, IEC 60811, EN 60228 | ||
Hazardous Area Certification No | ||
Cable CSA 0.5 mm² | ||
Fire Behaviour Flame Retardant acc. to IEC 60332-1-2 resp. EN 60332-1-2 | ||
American Wire Gauge 21AWG | ||
- COO (Country of Origin):
- FR
