Lapp ÖLFLEX CLASSIC 110 Control Cable, 2 Cores, 1.5 mm², YY, Unscreened, 50m, Black PVC Sheath, 16 AWG

RS Stock No.:: 144-923
Mfr. Part No.:: 1120306
Brand:: Lapp

Lapp ÖLFLEX CLASSIC 110 Control Cable, 2 Cores, 1.5 mm², YY, Unscreened, 50m, Black PVC Sheath, 16 AWG

Subtotal (1 reel of 50 metres)*

£97.34

(exc. VAT)

£116.81

(inc. VAT)

FREE delivery for orders over £50.00

In Stock

10 unit(s) ready to ship
Plus 2 unit(s) ready to ship from another location

Need more? Click ‘Check delivery dates’ to find extra stock and lead times.

Reel(s)	Per Reel	Per Metre*
1 +	£97.34	£1.947

*price indicative

RS Stock No.:: 144-923
Mfr. Part No.:: 1120306
Brand:: Lapp

Specifications

Technical Reference

Legislation and Compliance

Product Details

Find similar products by selecting one or more attributes.

Select all	Attribute	Value
	Brand	Lapp
	Series	ÖLFLEX CLASSIC 110
	Number of Cores	2
	Cross Sectional Area	1.5 mm²
	American Wire Gauge	16 AWG
	Conductor Material	Copper
	Sheath Material	PVC
	Sheath Colour	Black
	Control Cable Type	YY
	Screened/Unscreened	Unscreened
	Minimum Bend Radius	Static/Occasional moved: 4/15 x OD
	Length	50m
	Outer Diameter	9.6mm
	Voltage Rating	600/1000 V
	Current Rating	18 A
	CPR Certification	Eca
	Maximum Operating Temperature	+80°C
	Filler Material	Non-Wicking Filler
	Earth Cable	No
	Conductor Resistance	13.5 Ω/km
	Minimum Operating Temperature	-40°C
	Oil Resistant	Yes
	Insulation Material	PVC
	Core Strands	30/0.25 mm

	Select all
	Brand Lapp
	Series ÖLFLEX CLASSIC 110
	Number of Cores 2
	Cross Sectional Area 1.5 mm²
	American Wire Gauge 16 AWG
	Conductor Material Copper
	Sheath Material PVC
	Sheath Colour Black
	Control Cable Type YY
	Screened/Unscreened Unscreened
	Minimum Bend Radius Static/Occasional moved: 4/15 x OD
	Length 50m
	Outer Diameter 9.6mm
	Voltage Rating 600/1000 V
	Current Rating 18 A
	CPR Certification Eca
	Maximum Operating Temperature +80°C
	Filler Material Non-Wicking Filler
	Earth Cable No
	Conductor Resistance 13.5 Ω/km
	Minimum Operating Temperature -40°C
	Oil Resistant Yes
	Insulation Material PVC
	Core Strands 30/0.25 mm

COO (Country of Origin):: DE

LAPP ÖLFLEX CLASSIC 110 Series Control Cable, 1.5mm² Cross Sectional Area, 600/1000V Voltage Rating - 1120306

This control cable is designed for versatile applications in industrial settings. With a cross-sectional area of 1.5mm² and a length of 50m, it features a robust PVC sheath and a flexible round shape. It operates effectively in a temperature range of -40°C to +80°C, making it suitable for various environmental conditions.

Features & Benefits

• Excellent chemical resistance against acids and oils
• Supports a voltage rating of 600/1000 V
• Capable of handling occasional movements in usage
• Flame retardant, increasing safety in operational environments
• Unscreened design ensures simplicity and ease of use

Applications

• Ideal for use in plant engineering and construction
• Suitable for industrial machinery and power stations
• Utilised in heating and air conditioning systems
• Effective for automation and mechanical
• Recommended for use in outdoor environments with appropriate temperature monitoring

What challenges does this cable address in high-temperature environments?

It is designed to function efficiently in temperatures up to 80°C, making it suitable for high-temperature applications where standard cables may fail.

How does the construction of this cable benefit its performance in dynamic applications?

The cable's flexible design allows it to handle occasional movements, reducing wear and tear in dynamic installations, such as wind turbines.

What are the implications of its unscreened design for installation?

The unscreened design simplifies installation, reduces costs, and is particularly suitable where electromagnetic interference is not a concern.
