TRACOPOWER 4.7 μH 1.15 A Common Mode Choke 109 mΩ
- RS Stock No.:
- 228-7879
- Mfr. Part No.:
- TCK-154
- Brand:
- TRACOPOWER
Bulk discount available
Subtotal (1 tape of 10 units)*
£23.96
(exc. VAT)
£28.75
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 18 August 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Tape(s) | Per Tape | Per unit* |
|---|---|---|
| 1 - 4 | £23.96 | £2.396 |
| 5 - 9 | £23.24 | £2.324 |
| 10 - 24 | £22.52 | £2.252 |
| 25 - 49 | £21.56 | £2.156 |
| 50 + | £20.60 | £2.06 |
*price indicative
- RS Stock No.:
- 228-7879
- Mfr. Part No.:
- TCK-154
- Brand:
- TRACOPOWER
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | TRACOPOWER | |
| Product Type | Common Mode Choke | |
| Inductance | 4.7 μH | |
| Series | TCK | |
| Maximum DC Current | 1.15A | |
| Impedance | 109mΩ | |
| Test Frequency | 1 kHz | |
| Minimum Operating Temperature | -40°C | |
| Maximum Operating Temperature | 125°C | |
| Automotive Standard | No | |
| Inductance Tolerance | ±20 % | |
| Depth | 4mm | |
| Standards/Approvals | No | |
| Maximum DC Resistance | 109mΩ | |
| Length | 4.5mm | |
| Height | 3.2mm | |
| Select all | ||
|---|---|---|
Brand TRACOPOWER | ||
Product Type Common Mode Choke | ||
Inductance 4.7 μH | ||
Series TCK | ||
Maximum DC Current 1.15A | ||
Impedance 109mΩ | ||
Test Frequency 1 kHz | ||
Minimum Operating Temperature -40°C | ||
Maximum Operating Temperature 125°C | ||
Automotive Standard No | ||
Inductance Tolerance ±20 % | ||
Depth 4mm | ||
Standards/Approvals No | ||
Maximum DC Resistance 109mΩ | ||
Length 4.5mm | ||
Height 3.2mm | ||
RoHS Status: Exempt
- COO (Country of Origin):
- TW
The TRACOPOWER TCK-154 is a range of common mode chokes for use with Traco isolated DC-DC converters.
Rated current 1.15 A max
Operating temperature -40°C to +125°C
