Huber+Suhner 16_TNC-50-2-7/133_NE Series Coaxial Connector Cable Male TNC, 50 Ω, Right Angle Body Crimp
- RS Stock No.:
- 205-9050
- Distrelec Article No.:
- 302-15-026
- Mfr. Part No.:
- 16_TNC-50-2-7/133_NE
- Brand:
- Huber+Suhner
Subtotal (1 unit)*
£28.32
(exc. VAT)
£33.98
(inc. VAT)
FREE delivery for orders over £60.00
In Stock
- 2 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £28.32 |
*price indicative
- RS Stock No.:
- 205-9050
- Distrelec Article No.:
- 302-15-026
- Mfr. Part No.:
- 16_TNC-50-2-7/133_NE
- Brand:
- Huber+Suhner
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Huber+Suhner | |
| Coaxial Connector Type | TNC | |
| Product Type | Coaxial Connector | |
| Mount Type | Cable | |
| Impedance | 50Ω | |
| Orientation | Right Angle | |
| Connector Gender | Male | |
| Cable Type | Coaxial | |
| Size | Standard | |
| Bulkhead | No | |
| Operating Frequency | 2.5GHz | |
| Minimum Operating Temperature | -65°C | |
| Body Plating | Brass | |
| Polarity | Normal | |
| Termination Type | Crimp | |
| Maximum Operating Temperature | 165°C | |
| Series | 16_TNC-50-2-7/133_NE | |
| Contact Gender | Male | |
| Contact Material | Brass | |
| Standards/Approvals | No | |
| Contact Plating | Gold Plating | |
| Select all | ||
|---|---|---|
Brand Huber+Suhner | ||
Coaxial Connector Type TNC | ||
Product Type Coaxial Connector | ||
Mount Type Cable | ||
Impedance 50Ω | ||
Orientation Right Angle | ||
Connector Gender Male | ||
Cable Type Coaxial | ||
Size Standard | ||
Bulkhead No | ||
Operating Frequency 2.5GHz | ||
Minimum Operating Temperature -65°C | ||
Body Plating Brass | ||
Polarity Normal | ||
Termination Type Crimp | ||
Maximum Operating Temperature 165°C | ||
Series 16_TNC-50-2-7/133_NE | ||
Contact Gender Male | ||
Contact Material Brass | ||
Standards/Approvals No | ||
Contact Plating Gold Plating | ||
- COO (Country of Origin):
- CH
The Huber & Suhner coaxial connector has 50 Ohm impedance. The electrical cable that has an inner conductor surrounded by a tubular insulating layer, surrounded by a tubular conducting shield. It has 11 GHz interface frequency and the body made from brass material. Coaxial cable is durable, easy to install and are designed to carry signals over long distances.
Impedance 50 O
Interface frequency max. 11 GHz
Frequency range DC to 2.5 GHz
Return loss 32 dB
Centre contact soldered
Outer contact crimped
Weight 0.0196 kg
Operating temperature -65 °C to 165 °C
