30 V dc, 230V ac Auxiliary Release Circuit Trip for use with 1492-D DC Circuit Breaker, 188 Regional Circuit Breakers
- RS Stock No.:
- 125-1539
- Mfr. Part No.:
- 189-AB01
- Brand:
- Allen Bradley
Available to back order for despatch 10/06/2024
Added
Price Each
£15.85
(exc. VAT)
£19.02
(inc. VAT)
Units | Per unit |
1 + | £15.85 |
- RS Stock No.:
- 125-1539
- Mfr. Part No.:
- 189-AB01
- Brand:
- Allen Bradley
Legislation and Compliance
- COO (Country of Origin):
- DE
Product Details
1492 SP Series - Accessories
Professional range of Allen Bradley general purpose MCBs accessories from the 1492 series. Accessories include auxiliary contacts, single phase busbars, busbar end caps, protective shrouds, shunt trips and terminal power feeds. All accessories are highly reliable and excellent quality.
Allen Bradley Circuit Trip, NO Configuration, Bottom Mounting - 189-AB01
Use this circuit trip from Rockwell Automations Allen Bradley range with MCBs in the 1492-SPM Series to protect you and your equipment. As an auxiliary contact, its an additional component you can add to your MCB to help protect the main contact in the event of a ground, thermal overload or short-circuit fault. It indicates whether your breaker is open or closed, so you know if you need to respond to fault conditions by opening the contact to release current and prevent damage to your primary circuit breaker.
• Also compatible with RCBs from the 188-J series for versatility
• Mechanical endurance of 20,000 operations for low maintenance needs and increased reliability
• Operating temperature range of ‐25°C to +55°C, so it suits harsh environments
• Mechanical endurance of 20,000 operations for low maintenance needs and increased reliability
• Operating temperature range of ‐25°C to +55°C, so it suits harsh environments
Standards and Certifications
• UL 489
• CSA 22.2 No. 5
• IEC Overvoltage Category III, Insulation Group II (Housing), EN 60068-2
• CE
• IP20
• CSA 22.2 No. 5
• IEC Overvoltage Category III, Insulation Group II (Housing), EN 60068-2
• CE
• IP20
How do I mount this circuit trip?
Its practical clip-on mounting design makes this component easy to mount to your MCB without specialist tools. As it's a bottom-mounting component, it also helps you save space in your DIN rail setups.
Allen Bradley MCBs
Specifications
Attribute | Value |
---|---|
Range | Bulletin |
Series | 189-AB |
For Use With | 1492-D DC Circuit Breaker, 188 Regional Circuit Breakers |
Type | Auxiliary Release |
Rated Control Voltage | 30 V dc, 230V ac |
