Arcol, 3 Ω 100 W Wirewound Chassis Mount Resistor ±1 %
- RS Stock No.:
- 195-4192
- Distrelec Article No.:
- 301-64-194
- Mfr. Part No.:
- HS100E6 3R F M193
- Brand:
- Arcol
Bulk discount available
Subtotal (1 unit)*
£15.04
(exc. VAT)
£18.05
(inc. VAT)
Stock information currently inaccessible - Please check back later
Units | Per unit |
|---|---|
| 1 - 4 | £15.04 |
| 5 - 9 | £14.21 |
| 10 - 24 | £13.24 |
| 25 - 49 | £12.20 |
| 50 + | £10.65 |
*price indicative
- RS Stock No.:
- 195-4192
- Distrelec Article No.:
- 301-64-194
- Mfr. Part No.:
- HS100E6 3R F M193
- Brand:
- Arcol
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Arcol | |
| Product Type | Chassis Mount Resistor | |
| Resistance | 3Ω | |
| Power Rating | 100W | |
| Series | HS100 | |
| Package/Case | Aluminium | |
| Temperature Coefficient | 100 ppm/°C | |
| Tolerance | ±1 % | |
| Technology | Wirewound | |
| Automotive Standard | No | |
| Overall Length | 65.2mm | |
| Maximum Operating Temperature | 200°C | |
| Standards/Approvals | RoHS, MIL 18546, IEC 115 | |
| Overall Height | 24.1mm | |
| Overall Width | 47.5mm | |
| Select all | ||
|---|---|---|
Brand Arcol | ||
Product Type Chassis Mount Resistor | ||
Resistance 3Ω | ||
Power Rating 100W | ||
Series HS100 | ||
Package/Case Aluminium | ||
Temperature Coefficient 100 ppm/°C | ||
Tolerance ±1 % | ||
Technology Wirewound | ||
Automotive Standard No | ||
Overall Length 65.2mm | ||
Maximum Operating Temperature 200°C | ||
Standards/Approvals RoHS, MIL 18546, IEC 115 | ||
Overall Height 24.1mm | ||
Overall Width 47.5mm | ||
- COO (Country of Origin):
- GB
100 watt aluminium housed power resistor. Designed for direct heatsink mounting with thermal compound to achieve maximum performance.
High Power to volume
Wound to maximise High Pulse Capability
Values from R005 to 100K
