Arcol, 50Ω 100W Wire Wound Chassis Mount Resistor HS100E6 50R F M193 ±1%
- RS Stock No.:
- 195-4206
- Distrelec Article No.:
- 301-64-200
- Mfr. Part No.:
- HS100E6 50R F M193
- Brand:
- Arcol
Bulk discount available
Subtotal (1 unit)*
£13.65
(exc. VAT)
£16.38
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- Plus 8 unit(s) shipping from 27 October 2025
- Plus 32 unit(s) shipping from 07 January 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 - 4 | £13.65 |
| 5 - 9 | £12.90 |
| 10 - 24 | £12.01 |
| 25 - 49 | £11.08 |
| 50 + | £9.68 |
*price indicative
- RS Stock No.:
- 195-4206
- Distrelec Article No.:
- 301-64-200
- Mfr. Part No.:
- HS100E6 50R F M193
- Brand:
- Arcol
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Arcol | |
| Resistance | 50Ω | |
| Power Rating | 100W | |
| Series | HS100 | |
| Package/Case | Aluminium Housed | |
| Tolerance | ±1% | |
| Technology | Wire Wound | |
| Minimum Temperature Coefficient | -100ppm/°C | |
| Maximum Temperature Coefficient | +100ppm/°C | |
| Dimensions | 65.2 x 47.5 x 24.1mm | |
| Overall Length | 65.2mm | |
| Overall Height | 24.1mm | |
| Overall Width | 47.5mm | |
Select all | ||
|---|---|---|
Brand Arcol | ||
Resistance 50Ω | ||
Power Rating 100W | ||
Series HS100 | ||
Package/Case Aluminium Housed | ||
Tolerance ±1% | ||
Technology Wire Wound | ||
Minimum Temperature Coefficient -100ppm/°C | ||
Maximum Temperature Coefficient +100ppm/°C | ||
Dimensions 65.2 x 47.5 x 24.1mm | ||
Overall Length 65.2mm | ||
Overall Height 24.1mm | ||
Overall Width 47.5mm | ||
- COO (Country of Origin):
- GB
100 watt aluminium housed power resistor. Designed for direct heatsink mounting with thermal compound to achieve maximum performance.
High Power to volume
Wound to maximise High Pulse Capability
Values from R005 to 100K
Wound to maximise High Pulse Capability
Values from R005 to 100K
