RS PRO, 300 Ω 100 W Wirewound Chassis Mount Resistor ±5 %
- RS Stock No.:
- 185-2406
- Brand:
- RS PRO
Bulk discount available
Subtotal (1 unit)*
£12.78
(exc. VAT)
£15.34
(inc. VAT)
FREE delivery for orders over £60.00
Being discontinued
- Final 9 unit(s), ready to ship
Units | Per unit |
|---|---|
| 1 - 4 | £12.78 |
| 5 - 9 | £11.50 |
| 10 - 19 | £10.39 |
| 20 + | £9.06 |
*price indicative
- RS Stock No.:
- 185-2406
- Brand:
- RS PRO
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | RS PRO | |
| Resistance | 300Ω | |
| Product Type | Chassis Mount Resistor | |
| Power Rating | 100W | |
| Series | RSLPR100 | |
| Package/Case | Aluminium | |
| Tolerance | ±5 % | |
| Technology | Wirewound | |
| Automotive Standard | No | |
| Termination Style | Wire | |
| Overall Length | 100mm | |
| Minimum Operating Temperature | -25°C | |
| Maximum Operating Temperature | 250°C | |
| Standards/Approvals | RoHS | |
| Overall Width | 75mm | |
| Overall Height | 5.7mm | |
| Select all | ||
|---|---|---|
Brand RS PRO | ||
Resistance 300Ω | ||
Product Type Chassis Mount Resistor | ||
Power Rating 100W | ||
Series RSLPR100 | ||
Package/Case Aluminium | ||
Tolerance ±5 % | ||
Technology Wirewound | ||
Automotive Standard No | ||
Termination Style Wire | ||
Overall Length 100mm | ||
Minimum Operating Temperature -25°C | ||
Maximum Operating Temperature 250°C | ||
Standards/Approvals RoHS | ||
Overall Width 75mm | ||
Overall Height 5.7mm | ||
- COO (Country of Origin):
- IN
RS PRO Panel Mount Resistor
The RS PRO RSLPR100 series aluminium housed panel mount resistor has a resistance of 300ohm and power rating value of 100W. Its dimensions are 100mm x 75mm x 5.7mm (L x W x H). This low profile resistor is suitable for multiple industries and applications.
Features and Benefits
• Operating temperature ranging between -25°C and 250°C
• Tolerance: ±5%
• Dielectric strength: 2500VAC-rms for 1 minute
• Minimum insulation resistance: 100Mohm
Applications
• Electrical vehicles
• Power supplies
• Control devices
• Robotics
Certifications
• ANSI/ESD S20.20:2014
• BS EN 61340-5-1:2007
