Eaton 5 Position 45 °, Spring Return Actuator 20 A
- RS Stock No.:
- 255-021
- Mfr. Part No.:
- 226793 T0-2-8182/I1
- Brand:
- Eaton
Subtotal (1 unit)*
£54.85
(exc. VAT)
£65.82
(inc. VAT)
FREE delivery for orders over £60.00
Stocked by manufacturer
- Ready to ship from 03 November 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £54.85 |
*price indicative
- RS Stock No.:
- 255-021
- Mfr. Part No.:
- 226793 T0-2-8182/I1
- Brand:
- Eaton
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Eaton | |
| Series | Eaton Moeller T0 | |
| Product Type | Cam Switch | |
| Number of Positions | 5 | |
| Mount Type | Surface | |
| Number of Poles | 2 | |
| Terminal Type | Screw | |
| Angle of Throw | 45 ° | |
| IP Rating | IP65 | |
| Minimum Operating Temperature | -25°C | |
| Contact Current | 20A | |
| Contact Voltage | 690V | |
| Maximum Operating Temperature | 40°C | |
| Actuator Type | Spring Return | |
| Standards/Approvals | VDE 0660, VDE, IEC/EN 60947-3, IEC/EN 60947, IEC/EN 60204 | |
| Width | 8mm | |
| Hazardous Area Certification | No | |
| Depth | 102mm | |
| Length | 137mm | |
| Mechanical Life | 400000Operations | |
| Select all | ||
|---|---|---|
Brand Eaton | ||
Series Eaton Moeller T0 | ||
Product Type Cam Switch | ||
Number of Positions 5 | ||
Mount Type Surface | ||
Number of Poles 2 | ||
Terminal Type Screw | ||
Angle of Throw 45 ° | ||
IP Rating IP65 | ||
Minimum Operating Temperature -25°C | ||
Contact Current 20A | ||
Contact Voltage 690V | ||
Maximum Operating Temperature 40°C | ||
Actuator Type Spring Return | ||
Standards/Approvals VDE 0660, VDE, IEC/EN 60947-3, IEC/EN 60947, IEC/EN 60204 | ||
Width 8mm | ||
Hazardous Area Certification No | ||
Depth 102mm | ||
Length 137mm | ||
Mechanical Life 400000Operations | ||
RoHS Status: Exempt
- COO (Country of Origin):
- GB
The Eaton Moeller series T0 Spring return switch is designed for reliable and efficient control in various electrical applications. This innovative switch combines a robust design with versatile functionality tailored for modern electrical setups. Featuring a surface mounted device, it effectively handles up to 20 A of operational current with a degree of protection rated at IP65, ensuring durability in harsh environments. Its unique spring return mechanism allows for momentary or maintained operation, making it an exceptional choice for control panels or machinery requiring precise switching.
Surface mounted design for easy installation
Meets stringent IEC and EN standards for safety and reliability
IP65 rating provides dust and water resistance
Compact dimensions enable integration into tight spaces
Mechanical lifespan of 400000 operations ensures long term use
Suitable for a wide range of applications including control panels
Features innovative thermal stability and corrosion resistance
Robust construction withstands mechanical impacts and vibrations
