NSK-RHP Bearing Insert 20 mm ID 47 mm OD J1020-20GCR
- RS Stock No.:
- 192-9884
- Mfr. Part No.:
- J1020-20GCR
- Brand:
- NSK-RHP
Image representative of range
Bulk discount available
Subtotal (1 unit)*
£55.44
(exc. VAT)
£66.53
(inc. VAT)
FREE delivery for orders over £50.00
Stocked by manufacturer
- Ready to ship from 30 March 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 - 4 | £55.44 |
| 5 - 9 | £52.17 |
| 10 - 24 | £51.06 |
| 25 + | £50.01 |
*price indicative
- RS Stock No.:
- 192-9884
- Mfr. Part No.:
- J1020-20GCR
- Brand:
- NSK-RHP
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | NSK-RHP | |
| Inside Diameter | 20 mm | |
| Product Type | Bearing Insert | |
| Outside Diameter | 47 mm | |
| Material | Stainless Steel | |
| Static Load Rating | 5350N | |
| Dynamic Load Rating | 9910N | |
| Locking Type | Set Screw | |
| Standards/Approvals | No | |
| Series | J1020 | |
| Bore Type | Round | |
| Overall Width | 31mm | |
| Limiting Speed | 2900rpm | |
| Select all | ||
|---|---|---|
Brand NSK-RHP | ||
Inside Diameter 20 mm | ||
Product Type Bearing Insert | ||
Outside Diameter 47 mm | ||
Material Stainless Steel | ||
Static Load Rating 5350N | ||
Dynamic Load Rating 9910N | ||
Locking Type Set Screw | ||
Standards/Approvals No | ||
Series J1020 | ||
Bore Type Round | ||
Overall Width 31mm | ||
Limiting Speed 2900rpm | ||
- COO (Country of Origin):
- GB
Stainless Insert for 20mm Shaft 47x30.96x14mm
