SKF Bearing Inserts 60mm ID 75.64mm OD FY 50 TF/VA201
- RS Stock No.:
- 461-580
- Mfr. Part No.:
- FY 50 TF/VA201
- Brand:
- SKF
Subtotal (1 unit)*
£300.97
(exc. VAT)
£361.16
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 24 November 2025
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £300.97 |
*price indicative
- RS Stock No.:
- 461-580
- Mfr. Part No.:
- FY 50 TF/VA201
- Brand:
- SKF
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | SKF | |
| Inside Diameter | 60mm | |
| Outside Diameter | 75.64mm | |
| Material | Cast Iron | |
| Static Load Rating | 36kN | |
| Dynamic Load Rating | 52.7kN | |
Select all | ||
|---|---|---|
Brand SKF | ||
Inside Diameter 60mm | ||
Outside Diameter 75.64mm | ||
Material Cast Iron | ||
Static Load Rating 36kN | ||
Dynamic Load Rating 52.7kN | ||
- COO (Country of Origin):
- IT
Akshay
The SKF Square flanged ball bearing units are designed for high temperature applications and are compliant with ISO standards. They consist of a high temperature insert bearing, with an extended inner ring and set screw locking, and are suitable for applications where the direction of rotation is constant or alternating. The bearing is mounted in a cast iron housing, which can be bolted to a machine wall or frame. Ball bearing units can accommodate moderate initial misalignment, but normally do not permit axial displacement.
Resist high levels of contamination
Designed for high temperatures and speeds
Accommodate relatively heavy loads
Cost-effective
Designed for high temperatures and speeds
Accommodate relatively heavy loads
Cost-effective
