SKF Insert Bearing 31.75 mm ID 41.6 mm OD FY 1.1/4 TF
- RS Stock No.:
- 461-577
- Mfr. Part No.:
- FY 1.1/4 TF
- Brand:
- SKF
Subtotal (1 unit)*
£67.48
(exc. VAT)
£80.98
(inc. VAT)
Add 1 unit to get free delivery
Temporarily out of stock
- Shipping from 25 March 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £67.48 |
*price indicative
- RS Stock No.:
- 461-577
- Mfr. Part No.:
- FY 1.1/4 TF
- Brand:
- SKF
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | SKF | |
| Inside Diameter | 31.75 mm | |
| Product Type | Insert Bearing | |
| Outside Diameter | 41.6 mm | |
| Material | Cast Iron | |
| Static Load Rating | 15.3kN | |
| Dynamic Load Rating | 25.5kN | |
| Locking Type | Screw | |
| Series | FY 1.1/4 TF | |
| Standards/Approvals | RoHS | |
| Overall Width | 46.4mm | |
| Bore Type | Cylindrical | |
| Limiting Speed | 5300rpm | |
| Select all | ||
|---|---|---|
Brand SKF | ||
Inside Diameter 31.75 mm | ||
Product Type Insert Bearing | ||
Outside Diameter 41.6 mm | ||
Material Cast Iron | ||
Static Load Rating 15.3kN | ||
Dynamic Load Rating 25.5kN | ||
Locking Type Screw | ||
Series FY 1.1/4 TF | ||
Standards/Approvals RoHS | ||
Overall Width 46.4mm | ||
Bore Type Cylindrical | ||
Limiting Speed 5300rpm | ||
- COO (Country of Origin):
- IT
Zoya
The SKF Square flanged ball bearing units are compliant with ISO standards. They consist of an insert bearing, with an extended inner ring and set screw locking, and are suitable for applications where the direction of rotation is constant or alternating. The bearing is mounted in a cast iron housing, which can be bolted to a machine wall or frame.
Resist high levels of contamination
Designed for high temperatures and speeds
Accommodate relatively heavy loads
Cost effective
