SKF Bearing Insert 31.75 mm ID 62 mm OD YET 206-104
- RS Stock No.:
- 463-478
- Mfr. Part No.:
- YET 206-104
- Brand:
- SKF
Subtotal (1 unit)*
£35.47
(exc. VAT)
£42.56
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 05 March 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £35.47 |
*price indicative
- RS Stock No.:
- 463-478
- Mfr. Part No.:
- YET 206-104
- Brand:
- SKF
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | SKF | |
| Inside Diameter | 31.75 mm | |
| Product Type | Bearing Insert | |
| Outside Diameter | 62 mm | |
| Material | Steel | |
| Static Load Rating | 11.2kg | |
| Dynamic Load Rating | 19.5kN | |
| Locking Type | Eccentric Locking Collar | |
| Overall Width | 35.7mm | |
| Bore Type | Cylindrical | |
| Standards/Approvals | RoHS | |
| Series | YET 206-104 | |
| Limiting Speed | 6300rpm | |
| Select all | ||
|---|---|---|
Brand SKF | ||
Inside Diameter 31.75 mm | ||
Product Type Bearing Insert | ||
Outside Diameter 62 mm | ||
Material Steel | ||
Static Load Rating 11.2kg | ||
Dynamic Load Rating 19.5kN | ||
Locking Type Eccentric Locking Collar | ||
Overall Width 35.7mm | ||
Bore Type Cylindrical | ||
Standards/Approvals RoHS | ||
Series YET 206-104 | ||
Limiting Speed 6300rpm | ||
- COO (Country of Origin):
- IT
The SKF Insert bearings are based on sealed deep groove ball bearings. It is intended for use in applications where the direction of rotation is constant. It has a narrow inner ring extended on one side, with an eccentric locking collar, enabling quick and easy mounting onto the shaft.
Designed for rotation in one direction
Quick and easy to mount onto the shaft
Long service life
Reduce noise and vibration levels
