FAG 2308-2RS-TVH 40 mm ID 2 Row Ball Bearing -, 90 mm OD
- RS Stock No.:
- 260-0406
- Mfr. Part No.:
- 2308-2RS-TVH
- Brand:
- FAG
Subtotal (1 unit)*
£103.73
(exc. VAT)
£124.48
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 19 January 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £103.73 |
*price indicative
- RS Stock No.:
- 260-0406
- Mfr. Part No.:
- 2308-2RS-TVH
- Brand:
- FAG
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | FAG | |
| Inside Diameter | 40 mm | |
| Product Type | Ball Bearing | |
| Outside Diameter | 90 mm | |
| Race Width | 33mm | |
| Cage Material | Polyamide | |
| Ball Material | Steel | |
| End Type | Closed | |
| Number of Rows | 2 | |
| Static Load Rating | 9.7kN | |
| Dynamic Load Rating | 30kN | |
| Series | TVH | |
| Bore Type | Parallel | |
| Standards/Approvals | No | |
| Limiting Speed | 4650rpm | |
| Bearing Type | Self-Aligning | |
| Race Type | Plain | |
| Select all | ||
|---|---|---|
Brand FAG | ||
Inside Diameter 40 mm | ||
Product Type Ball Bearing | ||
Outside Diameter 90 mm | ||
Race Width 33mm | ||
Cage Material Polyamide | ||
Ball Material Steel | ||
End Type Closed | ||
Number of Rows 2 | ||
Static Load Rating 9.7kN | ||
Dynamic Load Rating 30kN | ||
Series TVH | ||
Bore Type Parallel | ||
Standards/Approvals No | ||
Limiting Speed 4650rpm | ||
Bearing Type Self-Aligning | ||
Race Type Plain | ||
RoHS Status: Exempt
- COO (Country of Origin):
- DE
The FAG self-aligning ball bearing has 40 mm bore diameter and 33 mm width with 4.650 1/min limiting speed.
Operating temperature -20 to 100 °C
