FAG 3000-2RS Double Row Angular Contact Ball Bearing- Both Sides Sealed 10mm I.D, 26mm O.D
- RS Stock No.:
- 190-8353
- Mfr. Part No.:
- 3000-2RS
- Brand:
- FAG
Bulk discount available
Subtotal (1 unit)*
£37.31
(exc. VAT)
£44.77
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 17 November 2025
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
---|---|
1 - 4 | £37.31 |
5 - 9 | £35.80 |
10 - 24 | £35.07 |
25 + | £34.31 |
*price indicative
- RS Stock No.:
- 190-8353
- Mfr. Part No.:
- 3000-2RS
- Brand:
- FAG
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
---|---|---|
Brand | FAG | |
Inside Diameter | 10mm | |
Outside Diameter | 26mm | |
Race Width | 12mm | |
Ball Bearing Type | Double Row Angular Contact Ball Bearing | |
Sealing Arrangement | Both Sides Sealed | |
Bearing Clearance | CN | |
Material | Steel | |
Ball Material | Steel | |
Cage Material | Plastic | |
Number of Rows | 2 | |
Static Load Rating | 3.2kN | |
Dynamic Load Rating | 5.7kN | |
Bore Type | Parallel | |
Clearance Code | CN | |
Bearing Series | 0 Extra Light | |
Race Type | Plain | |
Partial Bearing Code | 3000 | |
Select all | ||
---|---|---|
Brand FAG | ||
Inside Diameter 10mm | ||
Outside Diameter 26mm | ||
Race Width 12mm | ||
Ball Bearing Type Double Row Angular Contact Ball Bearing | ||
Sealing Arrangement Both Sides Sealed | ||
Bearing Clearance CN | ||
Material Steel | ||
Ball Material Steel | ||
Cage Material Plastic | ||
Number of Rows 2 | ||
Static Load Rating 3.2kN | ||
Dynamic Load Rating 5.7kN | ||
Bore Type Parallel | ||
Clearance Code CN | ||
Bearing Series 0 Extra Light | ||
Race Type Plain | ||
Partial Bearing Code 3000 | ||
Schaeffler 0 Extra Light Series Ball Bearing, 10mm Inside Diameter, 26mm Outside Diameter - 3000-2RS
This ball bearing belongs to the Schaeffler range and exemplifies precision engineering in its design. The double row angular contact ball bearing is crafted from durable steel and features sealed protection on both sides for enhanced longevity. With an inside diameter of 10mm and an outside diameter of 26mm, this bearing is designed to perform under dynamic loads and harsh conditions. Ideal for a variety of industrial applications, it combines strong load capacities with a lightweight construction.
Features & Benefits
• Double row design ensures greater load distribution
• Both sides sealed to keep contaminants out
• High static load rating of 3.2 kN for reliability
• Dynamic load rating of 5.7 kN for enhanced performance
• Suitable for low clearance applications with CN code
• Constructed from steel for robust durability
• Both sides sealed to keep contaminants out
• High static load rating of 3.2 kN for reliability
• Dynamic load rating of 5.7 kN for enhanced performance
• Suitable for low clearance applications with CN code
• Constructed from steel for robust durability
Applications
• Used in automation equipment for efficient movement
• Suitable for electric motors requiring high load bearings
• Ideal for machine tools needing precision and reliability
• Applicable in conveyor systems for material handling
• Utilised in various mechanisms within the mechanical industry
• Suitable for electric motors requiring high load bearings
• Ideal for machine tools needing precision and reliability
• Applicable in conveyor systems for material handling
• Utilised in various mechanisms within the mechanical industry
What specific advantages do sealed designs provide for longevity?
The sealed arrangement on both sides prevents dirt and moisture from entering the bearing, significantly extending its operational life and reducing maintenance frequency.
How does the double row design impact performance?
The double row configuration allows for better load distribution and increased stability, making it suitable for high load applications where precision is critical.
What maintenance practices ensure optimal performance?
Regular inspections should be performed to check for signs of wear or damage, and ensuring proper lubrication can aid in the smooth operation of the bearing.
In which environments is this ball bearing most effective?
This ball bearing performs well in industrial settings, particularly where there is a need for robust operation under dynamic loads and potential exposure to contaminants.
