SKF 61940 MA/C3 1 Row Deep Groove Ball Bearing - 200 mm ID, 280 mm OD
- RS Stock No.:
- 462-280
- Mfr. Part No.:
- 61940 MA/C3
- Brand:
- SKF
Subtotal (1 unit)*
£1,559.85
(exc. VAT)
£1,871.82
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 15 December 2025
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £1,559.85 |
*price indicative
- RS Stock No.:
- 462-280
- Mfr. Part No.:
- 61940 MA/C3
- Brand:
- SKF
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | SKF | |
| Product Type | Deep Groove Ball Bearing | |
| Inside Diameter | 200 mm | |
| Outside Diameter | 280 mm | |
| Race Width | 38mm | |
| Ball Material | Steel | |
| Cage Material | Machined Brass | |
| Number of Rows | 1 | |
| Internal Clearance | 117 μm | |
| Static Load Rating | 166kN | |
| Dynamic Load Rating | 148kN | |
| Bore Type | Cylindrical | |
| Standards/Approvals | No | |
| Series | 61940 | |
| Limiting Speed | 3800rpm | |
| Bearing Type | Deep Groove Ball | |
| Select all | ||
|---|---|---|
Brand SKF | ||
Product Type Deep Groove Ball Bearing | ||
Inside Diameter 200 mm | ||
Outside Diameter 280 mm | ||
Race Width 38mm | ||
Ball Material Steel | ||
Cage Material Machined Brass | ||
Number of Rows 1 | ||
Internal Clearance 117 μm | ||
Static Load Rating 166kN | ||
Dynamic Load Rating 148kN | ||
Bore Type Cylindrical | ||
Standards/Approvals No | ||
Series 61940 | ||
Limiting Speed 3800rpm | ||
Bearing Type Deep Groove Ball | ||
- COO (Country of Origin):
- FR
Gavin
The SKF Single row deep groove ball bearings with seals or shields are particularly versatile, have low friction and are optimized for low noise and low vibration, which enables high rotational speeds. They accommodate radial and axial loads in both directions, are easy to mount, and require less maintenance than many other bearing types. The integral sealing can significantly prolong bearing service life because it keeps lubricant in the bearings and contaminants out.
Low friction
High speed capability
Accommodate radial and axial loads in both directions
