SKF 2315 K 75 mm ID 2 Row Self-Aligning Ball Bearing -, 160 mm OD
- RS Stock No.:
- 462-223
- Mfr. Part No.:
- 2315 K
- Brand:
- SKF
Subtotal (1 unit)*
£462.56
(exc. VAT)
£555.07
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 05 January 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £462.56 |
*price indicative
- RS Stock No.:
- 462-223
- Mfr. Part No.:
- 2315 K
- Brand:
- SKF
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | SKF | |
| Product Type | Self-Aligning Ball Bearing | |
| Inside Diameter | 75 mm | |
| Outside Diameter | 160 mm | |
| Race Width | 55mm | |
| Ball Material | Bearing Steel | |
| Cage Material | Sheet Metal | |
| Number of Rows | 2 | |
| Internal Clearance | CN | |
| Static Load Rating | 43kN | |
| Dynamic Load Rating | 124kN | |
| Series | 2315 K | |
| Bore Type | Tapered 1:12 | |
| Standards/Approvals | RoHS | |
| Limiting Speed | 5600rpm | |
| Bearing Type | Self-aligning Ball Bearing | |
| Flange Outside Diameter | 160mm | |
| Select all | ||
|---|---|---|
Brand SKF | ||
Product Type Self-Aligning Ball Bearing | ||
Inside Diameter 75 mm | ||
Outside Diameter 160 mm | ||
Race Width 55mm | ||
Ball Material Bearing Steel | ||
Cage Material Sheet Metal | ||
Number of Rows 2 | ||
Internal Clearance CN | ||
Static Load Rating 43kN | ||
Dynamic Load Rating 124kN | ||
Series 2315 K | ||
Bore Type Tapered 1:12 | ||
Standards/Approvals RoHS | ||
Limiting Speed 5600rpm | ||
Bearing Type Self-aligning Ball Bearing | ||
Flange Outside Diameter 160mm | ||
- COO (Country of Origin):
- MY
Rupali
The SKF Self aligning ball bearings, with a tapered bore, have two rows of balls, a common sphered raceway in the outer ring and two deep uninterrupted raceway grooves in the inner ring. They are insensitive to angular misalignment of the shaft relative to the housing, which can be caused, for example, by shaft deflection. The tapered bore facilitates ease of mounting via adapter sleeves or withdrawal sleeves.
Ease of mounting via adapter sleeves or withdrawal sleeves
Accommodate static and dynamic misalignment
Excellent high speed performance
Excellent light load performance
Low friction
