SKF 61832/C3 1 Row Deep Groove Ball Bearing - 160 mm ID, 200 mm OD
- RS Stock No.:
- 461-967
- Mfr. Part No.:
- 61832/C3
- Brand:
- SKF
Subtotal (1 unit)*
£456.52
(exc. VAT)
£547.82
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 23 February 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £456.52 |
*price indicative
- RS Stock No.:
- 461-967
- Mfr. Part No.:
- 61832/C3
- Brand:
- SKF
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | SKF | |
| Product Type | Deep Groove Ball Bearing | |
| Inside Diameter | 160 mm | |
| Outside Diameter | 200 mm | |
| Race Width | 20mm | |
| Ball Material | Steel | |
| Cage Material | Sheet Metal | |
| Number of Rows | 1 | |
| Internal Clearance | 91 μm | |
| Static Load Rating | 64kN | |
| Dynamic Load Rating | 49.4kN | |
| Standards/Approvals | No | |
| Bore Type | Cylindrical | |
| Series | 61832 | |
| Limiting Speed | 4000rpm | |
| Bearing Type | Deep Groove Ball | |
| Select all | ||
|---|---|---|
Brand SKF | ||
Product Type Deep Groove Ball Bearing | ||
Inside Diameter 160 mm | ||
Outside Diameter 200 mm | ||
Race Width 20mm | ||
Ball Material Steel | ||
Cage Material Sheet Metal | ||
Number of Rows 1 | ||
Internal Clearance 91 μm | ||
Static Load Rating 64kN | ||
Dynamic Load Rating 49.4kN | ||
Standards/Approvals No | ||
Bore Type Cylindrical | ||
Series 61832 | ||
Limiting Speed 4000rpm | ||
Bearing Type Deep Groove Ball | ||
- COO (Country of Origin):
- FR
Gavin
The SKF Single row deep groove ball bearings with seals or shields are particularly versatile, have low friction and are optimized for low noise and low vibration, which enables high rotational speeds. They accommodate radial and axial loads in both directions, are easy to mount, and require less maintenance than many other bearing types. The integral sealing can significantly prolong bearing service life because it keeps lubricant in the bearings and contaminants out.
Low friction
High speed capability
Accommodate radial and axial loads in both directions
