SKF 7016 CDGA/P4A 1 Row Angular Contact Ball Bearing - 80 mm ID, 125 mm OD 22 mm Race Width
- RS Stock No.:
- 461-882
- Mfr. Part No.:
- 7016 CDGA/P4A
- Brand:
- SKF
Subtotal (1 unit)*
£551.97
(exc. VAT)
£662.36
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 30 December 2025
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £551.97 |
*price indicative
- RS Stock No.:
- 461-882
- Mfr. Part No.:
- 7016 CDGA/P4A
- Brand:
- SKF
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | SKF | |
| Product Type | Angular Contact Ball Bearing | |
| Inside Diameter | 80 mm | |
| Outside Diameter | 125 mm | |
| Race Width | 22mm | |
| Race Material | Steel | |
| Ball Material | Steel | |
| End Type | Open | |
| Number of Rows | 1 | |
| Contact Angle | 15° | |
| Static Load Rating | 61kN | |
| Dynamic Load Rating | 65kN | |
| Standards/Approvals | RoHS | |
| Series | 7016 | |
| Limiting Speed | 10000rpm | |
| Bearing Type | Angular Contact | |
| Race Type | Grooved | |
| Select all | ||
|---|---|---|
Brand SKF | ||
Product Type Angular Contact Ball Bearing | ||
Inside Diameter 80 mm | ||
Outside Diameter 125 mm | ||
Race Width 22mm | ||
Race Material Steel | ||
Ball Material Steel | ||
End Type Open | ||
Number of Rows 1 | ||
Contact Angle 15° | ||
Static Load Rating 61kN | ||
Dynamic Load Rating 65kN | ||
Standards/Approvals RoHS | ||
Series 7016 | ||
Limiting Speed 10000rpm | ||
Bearing Type Angular Contact | ||
Race Type Grooved | ||
- COO (Country of Origin):
- IT
Gavin
The SKF Angular Contact Ball Bearing is engineered for high-capacity performance in a variety of applications. Designed to accommodate both radial and unidirectional axial loads, it ensures remarkable stability under heavy loads and moderate speeds. The universally matchable feature allows for seamless integration into different bearing arrangements, providing optimal load sharing without the need for shims. Its construction prioritises running accuracy and stiffness, making it an ideal choice for precision machinery, where reliability and performance are paramount. Moreover, this bearing excels in low to moderate temperature environments, ensuring prolonged operational efficiency.
Features a one piece inner and outer ring for enhanced durability
Incorporates high capacity design for increased performance
Free from shims simplifying installation and adjustments
Optimised for low maintenance with a sealing free design
