SKF 3208 A-2Z 2 Row Angular Contact Ball Bearing - 40 mm ID, 80 mm OD 30.2 mm Race Width
- RS Stock No.:
- 461-251
- Mfr. Part No.:
- 3208 A-2Z
- Brand:
- SKF
Subtotal (1 unit)*
£105.15
(exc. VAT)
£126.18
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 02 January 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £105.15 |
*price indicative
- RS Stock No.:
- 461-251
- Mfr. Part No.:
- 3208 A-2Z
- Brand:
- SKF
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | SKF | |
| Inside Diameter | 40 mm | |
| Product Type | Angular Contact Ball Bearing | |
| Outside Diameter | 80 mm | |
| Race Width | 30.2mm | |
| Ball Material | Bearing Steel | |
| Race Material | Bearing Steel | |
| Cage Material | Sheet Metal | |
| End Type | Double Shielded | |
| Number of Rows | 2 | |
| Contact Angle | 30° | |
| Static Load Rating | 36.5kN | |
| Internal Clearance | CN | |
| Dynamic Load Rating | 48kN | |
| Standards/Approvals | RoHS | |
| Series | 3208 | |
| Bore Type | Cylindrical | |
| Limiting Speed | 8000rpm | |
| Bearing Type | Double Row Angular Contact Ball | |
| Race Type | One Piece Inner and Outer Rings | |
| Select all | ||
|---|---|---|
Brand SKF | ||
Inside Diameter 40 mm | ||
Product Type Angular Contact Ball Bearing | ||
Outside Diameter 80 mm | ||
Race Width 30.2mm | ||
Ball Material Bearing Steel | ||
Race Material Bearing Steel | ||
Cage Material Sheet Metal | ||
End Type Double Shielded | ||
Number of Rows 2 | ||
Contact Angle 30° | ||
Static Load Rating 36.5kN | ||
Internal Clearance CN | ||
Dynamic Load Rating 48kN | ||
Standards/Approvals RoHS | ||
Series 3208 | ||
Bore Type Cylindrical | ||
Limiting Speed 8000rpm | ||
Bearing Type Double Row Angular Contact Ball | ||
Race Type One Piece Inner and Outer Rings | ||
- COO (Country of Origin):
- US
Omkar
The SKF Double row angular contact ball bearings, with seals or shields, correspond to a pair of single row angular contact ball bearings in a back-to-back arrangement, while requiring less axial space. Depending on the sealing execution, they can operate at high speeds and are more suitable than deep groove ball bearings for supporting large axial forces in both directions.
Accommodate relatively high radial loads, high axial loads in both directions and tilting moments
Suitable where a stiff bearing arrangement is required
Require less axial space than equivalent pair of single row angular contact ball bearings
