Sanyo Denki San Ace 109P Series Axial Fan, 24 V dc, DC Operation, 11.3cfm, 2.28W, 95mA Max, 40 x 40 x 28mm
- RS Stock No.:
- 191-9234
- Distrelec Article No.:
- 301-54-343
- Mfr. Part No.:
- 109P0424H3D01
- Brand:
- Sanyo Denki
Bulk discount available
Subtotal (1 unit)*
£14.94
(exc. VAT)
£17.93
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- 63 unit(s) ready to ship
- Plus 86 unit(s) ready to ship from another location
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 - 4 | £14.94 |
| 5 - 9 | £14.04 |
| 10 - 24 | £13.13 |
| 25 - 49 | £12.54 |
| 50 + | £11.34 |
*price indicative
- RS Stock No.:
- 191-9234
- Distrelec Article No.:
- 301-54-343
- Mfr. Part No.:
- 109P0424H3D01
- Brand:
- Sanyo Denki
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Sanyo Denki | |
| Supply Voltage | 24 V dc | |
| AC or DC Operation | DC | |
| Height | 40mm | |
| Power Consumption | 2.28W | |
| Width | 40mm | |
| Maximum Current | 95mA | |
| Depth | 28mm | |
| Termination Type | Lead Wire | |
| Dimensions | 40 x 40 x 28mm | |
| Air Flow | 11.3cfm | |
| Noise Level | 37dB(A) | |
| Direction of Curve | Forward | |
| Bearing Type | Ball | |
Select all | ||
|---|---|---|
Brand Sanyo Denki | ||
Supply Voltage 24 V dc | ||
AC or DC Operation DC | ||
Height 40mm | ||
Power Consumption 2.28W | ||
Width 40mm | ||
Maximum Current 95mA | ||
Depth 28mm | ||
Termination Type Lead Wire | ||
Dimensions 40 x 40 x 28mm | ||
Air Flow 11.3cfm | ||
Noise Level 37dB(A) | ||
Direction of Curve Forward | ||
Bearing Type Ball | ||
- COO (Country of Origin):
- PH
Sanyo Denki Axial Fan, 37dB Noise Level, 40mm Height - San Ace 109P Series - 109P0424H3D01
For reliable cooling of industrial machines, choose this axial fan from Sanyo Denki. Its impeller draws air in and pushes it out at an airflow rate of 19.2m³/h for effective ventilation. Thanks to its long service life of 60,000 hours at +60°C, this fan is a long-lasting choice. For added safety, this device features locked rotor burnout protection and reverse polarity protection.
Features & Benefits
• Low current rating of 95mA for energy efficiency
• Light weight of 52g to place minimal strain on your system
• Low noise level of 37dB means it won't add too much background noise to your work environment
• Light weight of 52g to place minimal strain on your system
• Low noise level of 37dB means it won't add too much background noise to your work environment
Applications
• ICT equipment
• Network servers
• HVAC systems
• Process cooling
• Network servers
• HVAC systems
• Process cooling
Is this unit flame-resistant?
Yes. The unit's frame and impeller are made of flame-retardant plastic that will stop burning in 10 to 30 seconds in the event of a fire, making it safe for use in fire-prone areas.
Can I use this fan at extreme temperatures?
Yes, thanks to its broad operating temperature range of -20°C to +70°C, this unit is suitable for use in demanding conditions.
