RS PRO 7 Core, 4 mm² CSA, 14 x 5mm od, 100m, Brown
- RS Stock No.:
- 214-9612
- Brand:
- RS PRO
Subtotal (1 reel of 100 metres)*
£508.16
(exc. VAT)
£609.79
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- 1 unit(s) shipping from 06 January 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Reel(s) | Per Reel | Per Metre* |
|---|---|---|
| 1 + | £508.16 | £5.082 |
*price indicative
- RS Stock No.:
- 214-9612
- Brand:
- RS PRO
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | RS PRO | |
| Number of Cores | 7 | |
| Cross Sectional Area | 4 mm² | |
| Insulation Material | PVC | |
| Outer Diameter | 14 x 5mm | |
| Length | 100m | |
| Minimum Operating Temperature | -20°C | |
| Maximum Operating Temperature | +70°C | |
| Sheath Colour | Brown | |
| Size of Strands | 0.1 mm | |
| Conductor Material | Oxygen Free Copper | |
| Sheath Material | PVC | |
| Core Strands | 73/0.1 mm | |
| Number of Strands | 73 | |
| Screen Type | PVC | |
| Cable Shape | Multicore | |
Select all | ||
|---|---|---|
Brand RS PRO | ||
Number of Cores 7 | ||
Cross Sectional Area 4 mm² | ||
Insulation Material PVC | ||
Outer Diameter 14 x 5mm | ||
Length 100m | ||
Minimum Operating Temperature -20°C | ||
Maximum Operating Temperature +70°C | ||
Sheath Colour Brown | ||
Size of Strands 0.1 mm | ||
Conductor Material Oxygen Free Copper | ||
Sheath Material PVC | ||
Core Strands 73/0.1 mm | ||
Number of Strands 73 | ||
Screen Type PVC | ||
Cable Shape Multicore | ||
- COO (Country of Origin):
- TW
RS PRO 7-Core PVC Sheathed Speaker Cable
From the trusted RS PRO brand, this loudspeaker cable has a robust PVC outer jacket suitable for more rugged applications. With seven copper core conductors in twisted strands, each with transparent PVC insulation, the cable offers excellent conductivity for audio purposes. The robust outer insulation ensures the cable is resistant to abrasion and damage that might be caused by tugging or pulling, meaning it is ideally suited for demanding cabling installations. This multicore cable is engineered from pure OFC copper for optimum efficiency due to its durability resistance to shorts and long-life span as it's less likely to corrode than other wires.
Features and Benefits
- High-end quality speaker cable
- Speaker cables designed to be flexible for easy routing
- Offers excellent sound quality
- OFC Copper conductors provide heat and corrosion resistance
- Operating Temperature Range -20°C to +90 °C
Applications
Speaker cable, or speaker wire, is designed specifically to make an electrical connection between speakers and amplifiers, and as such is suited to several audio applications. From professional loudspeaker installation to domestic home cinema and hi-fi connections, speaker cable is the most common and effective way to wire speakers in audio setups. Multicore speaker cables can be found in industrial and domestic environments such as
Live stages and theatres
Audio & sound system
Professional studio
Touring
Hobbyist and custom audio setups
Live stages and theatres
Audio & sound system
Professional studio
Touring
Hobbyist and custom audio setups
Operating temperature -20°C to +90°C
Conductor resistance 5.0 Ω/Km
Conductor resistance 5.0 Ω/Km
