Vishay 2200μF Aluminium Electrolytic Capacitor 80V dc, Snap-In - MAL225632222E3
- RS Stock No.:
- 875-2658
- Mfr. Part No.:
- MAL225632222E3
- Brand:
- Vishay
Save 24% when you buy 100 units
Subtotal (1 unit)*
£7.15
(exc. VAT)
£8.58
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- 38 unit(s) ready to ship
- Plus 1 unit(s) ready to ship from another location
- Plus 24 unit(s) shipping from 09 October 2025
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
---|---|
1 - 9 | £7.15 |
10 - 24 | £6.79 |
25 - 49 | £6.43 |
50 - 99 | £6.08 |
100 + | £5.37 |
*price indicative
- RS Stock No.:
- 875-2658
- Mfr. Part No.:
- MAL225632222E3
- Brand:
- Vishay
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
---|---|---|
Brand | Vishay | |
Capacitance | 2200µF | |
Voltage | 80V dc | |
Mounting Type | Snap-In | |
Technology | Aluminium Electrolytic | |
Dimensions | 26 (Dia.) x 32mm | |
Height | 32mm | |
Minimum Operating Temperature | -40°C | |
Diameter | 26mm | |
Maximum Operating Temperature | +105°C | |
Lead Pitch | 10mm | |
Lifetime | 2000h | |
Tolerance | ±20% | |
Ripple Current | 1.65A | |
Leakage Current | 1.26 mA | |
Series | 256 | |
Equivalent Series Resistance | 151mΩ | |
Select all | ||
---|---|---|
Brand Vishay | ||
Capacitance 2200µF | ||
Voltage 80V dc | ||
Mounting Type Snap-In | ||
Technology Aluminium Electrolytic | ||
Dimensions 26 (Dia.) x 32mm | ||
Height 32mm | ||
Minimum Operating Temperature -40°C | ||
Diameter 26mm | ||
Maximum Operating Temperature +105°C | ||
Lead Pitch 10mm | ||
Lifetime 2000h | ||
Tolerance ±20% | ||
Ripple Current 1.65A | ||
Leakage Current 1.26 mA | ||
Series 256 | ||
Equivalent Series Resistance 151mΩ | ||
256 Series
MAL256 Series Polarized Aluminium Electrolytic Capacitors, non-solid electrolyte
Pressure relief on the top of the Aluminium case
PET insulation sleeve
Pressure relief on the top of the Aluminium case
PET insulation sleeve
Useful life of 2000h at +105°C and greater than 5000h at +85°C
Voltage range from 16V to 100V
Applications in General purpose, industrial; Standard and Switched Mode Power Supplies; Audio systems; DC/DC converters; Telecom; Smoothing and Filtering
Voltage range from 16V to 100V
Applications in General purpose, industrial; Standard and Switched Mode Power Supplies; Audio systems; DC/DC converters; Telecom; Smoothing and Filtering
