Cornell-Dubilier 8200μF Aluminium Electrolytic Capacitor 63V dc, Snap-In - 380LX822M063A032
- RS Stock No.:
- 871-4280
- Mfr. Part No.:
- 380LX822M063A032
- Brand:
- Cornell-Dubilier
Unavailable
RS will no longer stock this product.
- RS Stock No.:
- 871-4280
- Mfr. Part No.:
- 380LX822M063A032
- Brand:
- Cornell-Dubilier
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Cornell-Dubilier | |
| Capacitance | 8200µF | |
| Voltage | 63V dc | |
| Mounting Type | Snap-In | |
| Technology | Aluminium Electrolytic | |
| Dimensions | 35 x 35mm | |
| Length | 35mm | |
| Minimum Operating Temperature | -40°C | |
| Diameter | 35mm | |
| Maximum Operating Temperature | +85°C | |
| Lead Pitch | 10mm | |
| Lifetime | 1000 (Shelf) h, 3000 (Endurance) h | |
| Ripple Current | 6 A @ 120 Hz, 6.9 A @ 20 kHz | |
| Series | 380LX | |
| Equivalent Series Resistance | 40 mΩ @ 20 kHz, 50 mΩ @ 120 Hz | |
| Tolerance | ±20% | |
Select all | ||
|---|---|---|
Brand Cornell-Dubilier | ||
Capacitance 8200µF | ||
Voltage 63V dc | ||
Mounting Type Snap-In | ||
Technology Aluminium Electrolytic | ||
Dimensions 35 x 35mm | ||
Length 35mm | ||
Minimum Operating Temperature -40°C | ||
Diameter 35mm | ||
Maximum Operating Temperature +85°C | ||
Lead Pitch 10mm | ||
Lifetime 1000 (Shelf) h, 3000 (Endurance) h | ||
Ripple Current 6 A @ 120 Hz, 6.9 A @ 20 kHz | ||
Series 380LX | ||
Equivalent Series Resistance 40 mΩ @ 20 kHz, 50 mΩ @ 120 Hz | ||
Tolerance ±20% | ||
Cornell-Dubilier 380LX Series
Cornell-Dubilier 380LX series snap-in aluminium electrolytic capacitors offer a long life and high capacitance per can size. The 380LX readily handles tough switching power supply input and output circuits and motor-drive bus capacitor applications.
Features and Benefits:
High temperature range
Compact can size
Long life
High capacitance per can size
Variety of case sizes
High temperature range
Compact can size
Long life
High capacitance per can size
Variety of case sizes
