Nichicon 2200μF Aluminium Electrolytic Capacitor 100V dc, Snap-In - LGU2A222MELA
- RS Stock No.:
- 846-6988
- Mfr. Part No.:
- LGU2A222MELA
- Brand:
- Nichicon
Sorry, we couldn't check our stock levels right now. Please try refreshing the page.
Not available for guaranteed pre 9am/10am delivery
Added
Price Each
£3.68
(exc. VAT)
£4.42
(inc. VAT)
| Units | Per unit |
| 1 - 4 | £3.68 |
| 5 - 9 | £3.50 |
| 10 - 24 | £3.31 |
| 25 - 49 | £3.13 |
| 50 + | £2.94 |
- RS Stock No.:
- 846-6988
- Mfr. Part No.:
- LGU2A222MELA
- Brand:
- Nichicon
Technical Reference
Legislation and Compliance
- COO (Country of Origin):
- MY
Product Details
Aluminium Electrolytic Capacitors GU Series 105°C
Nichicon GU Series Snap-In Aluminium Electrolytic Capacitors can withstand 3000 hours of rated ripple current application. The snap-in terminal GU Series Aluminium Electrolytic Capacitors from Nichicon offer a large capacitance range with voltages ranging from 16 to 450V. These high performance capacitors have a wide temperature range which is ideal for applications such as uninterruptible power supplies, electric pump motors, and AC servomotors.
Snap-In terminals
Endurance rating ripple current 3000 hours guaranteed
PET sleeve (non PVC)
Lead-free terminal plating
Endurance rating ripple current 3000 hours guaranteed
PET sleeve (non PVC)
Lead-free terminal plating
Specifications
Attribute | Value |
|---|---|
| Capacitance | 2200µF |
| Voltage | 100V dc |
| Mounting Type | Snap-In |
| Technology | Aluminium Electrolytic |
| Dimensions | 25 (Dia.) x 50mm |
| Height | 50mm |
| Minimum Operating Temperature | -40°C |
| Diameter | 25mm |
| Maximum Operating Temperature | +105°C |
| Lead Pitch | 10mm |
| Lifetime | 3000h |
| Series | GU |
| Tolerance | ±20% |
| Ripple Current | 2.57A |
| Leakage Current | 1.4 mA |
