Bulk discount available
Subtotal (1 pack of 2 units)*
£9.01
(exc. VAT)
£10.812
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- 36 unit(s) ready to ship
- Plus 12 unit(s) ready to ship from another location
- Plus 200 unit(s) shipping from 09 September 2025
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Pack* |
|---|---|---|
| 2 - 18 | £4.505 | £9.01 |
| 20 - 48 | £4.185 | £8.37 |
| 50 - 98 | £3.87 | £7.74 |
| 100 - 198 | £3.69 | £7.38 |
| 200 + | £3.355 | £6.71 |
*price indicative
- RS Stock No.:
- 706-3348
- Brand:
- RS PRO
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | RS PRO | |
| Capacitance | 470µF | |
| Voltage | 160V dc | |
| Mounting Type | Snap-In | |
| Technology | Aluminium Electrolytic | |
| Dimensions | 22 (Dia.) x 35mm | |
| Height | 35mm | |
| Length | 35mm | |
| Minimum Operating Temperature | -25°C | |
| Diameter | 22mm | |
| Maximum Operating Temperature | 105°C | |
| Lead Pitch | 10mm | |
| Lifetime | 2000h | |
| Tolerance | ±20% | |
| Leakage Current | <=0.02 CV @ 5 min | |
| Series | RS | |
| Ripple Current | 1.21A | |
| Polarised | Polar | |
| Dissipation Factor | 15% | |
Select all | ||
|---|---|---|
Brand RS PRO | ||
Capacitance 470µF | ||
Voltage 160V dc | ||
Mounting Type Snap-In | ||
Technology Aluminium Electrolytic | ||
Dimensions 22 (Dia.) x 35mm | ||
Height 35mm | ||
Length 35mm | ||
Minimum Operating Temperature -25°C | ||
Diameter 22mm | ||
Maximum Operating Temperature 105°C | ||
Lead Pitch 10mm | ||
Lifetime 2000h | ||
Tolerance ±20% | ||
Leakage Current <=0.02 CV @ 5 min | ||
Series RS | ||
Ripple Current 1.21A | ||
Polarised Polar | ||
Dissipation Factor 15% | ||
