Vishay 390 μF Capacitor 570V dc, Through Hole - MAL219390123E3
- RS Stock No.:
- 249-7397
- Mfr. Part No.:
- MAL219390123E3
- Brand:
- Vishay
Subtotal (1 box of 100 units)*
£1,359.00
(exc. VAT)
£1,631.00
(inc. VAT)
FREE delivery for orders over £60.00
Temporarily out of stock
- Shipping from 07 May 2027
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Box* |
|---|---|---|
| 100 + | £13.59 | £1,359.00 |
*price indicative
- RS Stock No.:
- 249-7397
- Mfr. Part No.:
- MAL219390123E3
- Brand:
- Vishay
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Vishay | |
| Product Type | Capacitor | |
| Capacitance | 390μF | |
| Voltage | 570V dc | |
| Mount Type | Through Hole | |
| Packaging | Box | |
| Height | 45mm | |
| Polarity | Polar | |
| Minimum Operating Temperature | -40°C | |
| Diameter | 35mm | |
| Termination Type | Snap-In | |
| Capacitor Ripple Current | 1.9A | |
| Pin Count | 2 | |
| Maximum Operating Temperature | 105°C | |
| Lifetime | 6000 h | |
| Standards/Approvals | RoHS | |
| Lead Pitch | 10mm | |
| Automotive Standard | No | |
| Series | 193 PUR-SI Solar | |
| Equivalent Series Resistance ESR | 600mΩ | |
| Tolerance | ±20 % | |
| Leakage Current | 1.2mA | |
| Select all | ||
|---|---|---|
Brand Vishay | ||
Product Type Capacitor | ||
Capacitance 390μF | ||
Voltage 570V dc | ||
Mount Type Through Hole | ||
Packaging Box | ||
Height 45mm | ||
Polarity Polar | ||
Minimum Operating Temperature -40°C | ||
Diameter 35mm | ||
Termination Type Snap-In | ||
Capacitor Ripple Current 1.9A | ||
Pin Count 2 | ||
Maximum Operating Temperature 105°C | ||
Lifetime 6000 h | ||
Standards/Approvals RoHS | ||
Lead Pitch 10mm | ||
Automotive Standard No | ||
Series 193 PUR-SI Solar | ||
Equivalent Series Resistance ESR 600mΩ | ||
Tolerance ±20 % | ||
Leakage Current 1.2mA | ||
- COO (Country of Origin):
- CN
The Vishay Aluminium electrolytic capacitor which has capacitance of 390uF. They are used in solar PV inverters, industrial motor supply, power supply.
Long useful life 6000 h at +105 °C
Specified for 570 V, 60 °C operation
High ripple current capability
High Reliability
